Seasonic SSR-850PD (ULTRA ) PRIME Ultra 850W 80 PLUS Platinum ATX12V Power Supply
- New in Prime Ultra
- 80 PLUS Platinum
- Micro Tolerance Load Regulation
- Premium Hybrid Fan Control
- Fluid Dynamic Fan Bearing
- Cable-free Connection Design
+
+
Overview
Specs
Reviews
Detail Specifications 80PLUS Platinum Form Factor Intel ATX 12 V
Fan Information Fan Size: 135 mm
Fan Control: Premium Hybrid Fan
Control Fan Bearing: Fluid
Dynamic Bearing Life Expectancy: 70, 000 hours at 40 oC, 15 % - 65 % RH
Cable Information Modularity: Fully Modular
Cable type: Flat black cables
Electrical Features Operating Temperature: 0 - 50 oC MTBF 25 oC, excl.
fan: 150, 000 hours
AC Input: Full
Range Protection: OPP, OVP, UVP, OCP, OTP, SCP Safety and Environmental Safety and
EMC: cTUVus, TUV, CB, CCC, BSMI, EAC
Environmental Compliance: Energy Star, RoHS, WEEE, ErP Lot 6, REACH AC
Input Voltage: 100 V - 240
V Current: 10 - 5
A Frequency: 50 Hz - 60 Hz DC Output Rail / Maximum Power + 3.3 V / 20
A: 100 W +5 V / 20
A: 100 W +12 V / 62
A: 744 W -12 V/ 0.3
A: 3.6 W +5 VSB / 3
A: 15
W Total continuous power: 750 W
Fan Information Fan Size: 135 mm
Fan Control: Premium Hybrid Fan
Control Fan Bearing: Fluid
Dynamic Bearing Life Expectancy: 70, 000 hours at 40 oC, 15 % - 65 % RH
Cable Information Modularity: Fully Modular
Cable type: Flat black cables
Electrical Features Operating Temperature: 0 - 50 oC MTBF 25 oC, excl.
fan: 150, 000 hours
AC Input: Full
Range Protection: OPP, OVP, UVP, OCP, OTP, SCP Safety and Environmental Safety and
EMC: cTUVus, TUV, CB, CCC, BSMI, EAC
Environmental Compliance: Energy Star, RoHS, WEEE, ErP Lot 6, REACH AC
Input Voltage: 100 V - 240
V Current: 10 - 5
A Frequency: 50 Hz - 60 Hz DC Output Rail / Maximum Power + 3.3 V / 20
A: 100 W +5 V / 20
A: 100 W +12 V / 62
A: 744 W -12 V/ 0.3
A: 3.6 W +5 VSB / 3
A: 15
W Total continuous power: 750 W
