Panasonic PT-MZ770U 8000-Lumen WUXGA 3LCD Laser Projector (White, with 1.6 to 2.8:1 Lens)

Be the first to review this product...

Brightness of 8000 Lumens
WUXGA (1920 x 1200) Native Resolution
Includes 1.6 to 2.8:1 Lens
HDBaseT, BNC, VGA, RCA, 2x HDMI Inputs

Overview

Specs

Reviews

Panasonic PT-MZ770U WUXGA 8000 Lumen Laser Projector

Model
Brand	Panasonic
Model	PT-MZ770U

Details
Cabinet Color	White
Type	3-Chip 0.76" LCD

Display
Brightness	8000 Lumens
Native Resolution	1920 x 1200
Maximum Resolution	3840 x 2160
Aspect Ratio	16:10
Contrast Ratio	DCR 3,000,000:1
Display Size	40" to 400"

Lens
f Number	F/1.7 - 2.6
Focal Length	f = 26.8 - 45.5 mm
Throw Ratio	1.6 to 2.8:1
Throw Distance	11.4 - 19.6' / 3.47 - 5.97 m
Projection Methods	Front
Keystone Correction	Vertical: +/- 25° Horizontal: +/- 30°

Lamps & Accessories
Lamp	Laser
Lamp Life	Medium Brightness: 20,000 Hours

Connectivity
Input Video Compatibility	Analog RGB, Digital
Input Video Connectors	2 x HDMI (HDMI Type-A) Audio, Video Input 1 x BNC Video Input 1 x VGA (DE-15/DB-15) Video Input 1 x Composite (RCA) Video Input
Input Audio Connectors	3.5 mm Audio
Output Video Connectors	D-Sub
Output Audio Connectors	3.5 mm Audio
Network Connectors	RJ45
USB	Yes
Other Connectors	1 x RS-232 (DE-9/DB-9) Control Input 1 x DE-9/DB-9 Remote Input

Convenience
Built-in Speakers	10W
Features	Laser LCD, 8,000 lumens, WUXGA Compact and lightweight body, designed with ultra-low noise operation Exchangeable lenses (compatible with PT-EZ770 series lenses) for flexible installation in any meeting- or classroom Packed with a wide range of collaboration technologies such as 5 Ghz wireless projection from multiple devices, secure streaming & networking, PC-less presentation, audio loop-through and others Long lasting laser light source and low-maintenance design provide high brightness and superb image quality

Power
Power Supply	100 - 240 VAC, 50/60Hz
Power Consumption	570W (Max)

Environmental
Noise Level	Full Brightness: 35 dB Low Brightness: 28 dB

Dimensions & Weight
Dimensions (H x W x D)	8.10" x 22.10" x 17.40"
Weight	37.70 lbs.
