Specifications: Resolution: 3840 x 2160 at 30Hz (Dual Display)
Resolution: 3840 x 2160 at 60Hz (Single Display)
Output: Requires 5V, 2A external power over Micro-B USB port
DisplayPort 1.2a compliant
Link Rate: HBR2/HBR/RBR
Bandwidth: 5.4Gbps max.
Support SST and MST (when both host and monitor support)
Support 7.1 sound channel; max. sampling size 192KHz
Rating: Temp 80°C, Voltage 30V
Conductor Resistance: At 20°C max 30AWG: 376.95 O/KM
Insulation Resistance: 10M -KM min at 20°C DC 500V (EIA-364-21)
Dielectric Strength: AC 500V/1 minute no breakdown (EIA-364-20)
Impedance: Pairs (differential mode) 100±50HMS
Attenuation (max.): 5.02dB@100~450MHz; 7.695dB@1GHz; 12.595dB@2GHz; 17.495dB@3GHz; 22.395dB@4GHz; 27.295dB@5GHz; 32.195dB@6GHz; 37.095dB@7GHz
Return...
Specifications: M.2 SSD Support: M.2 (NGFF), B Key or B+M Key
Internal Interface: 1 x M.2 (NGFF, B-Key)
External Interface: Standard USB 3.0 Micro-B
Computer Interface: USB Type A required
USB cable connector: USB 3.0 Micro-B and USB 3.0 Type-A
USB cable length: 475mm / 18 inches
Features: OTG cable allow you add an extra female USB port to host device so that it can connect USB storage, keyboard / mouse, USB hub, and USB Ethernet adapter and more via this female USB port. Create a simple way to connect mobile devices to a USB capable computer for
