Features: With this little dongle plugged into an available standard USB port, your legacy devices (charger, power bank, computer) can turn into a USB-C enabled platform. You can easily hook up any USB-C peripherals (USB Type-C cable, USB Type-C flash drive, USB Type-C hub) that make use of the newer USB-C
Compatibility: OS Compatibility: OS Independent; No additional drivers or software required
Note: The USB Type-C ports are data only.
USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps.
The hub does not support DP Alt Mode or USB Power Delivery.
System and Cable Requirements: Available USB Type-C port - USB 3.0 (5Gbps)
Ports Spec: 4 x USB Type-A (9 pin) USB 3.0 Female
2 x USB Type-C (24 pin) USB 3.0 Female
1 x USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
1 x USB Type-B (9 pin) USB 3.0 Male
Compatibility: OS Compatibility
Windows 7, 8, 8.1, 10
Mac OS 10.11 to 10.13
Chrome OS
Ports Spec: 1 x USB Type-C (24 pin) USB 3.0 Male
1 x HDMI (19 pin) Female
1 x RJ-45 Female
2 x USB Type-A (9 pin) USB 3.0 Female
1 x SD Slot Female
1 x USB Type-C (24 pin) USB 3.0 Female
Specifications: USB Type C External Stereo Sound Adapter Connector A: USB Type C Male Port Connector B : 2 x 3.5 Female Port for Stereo output jack, Mono microphone-input jack Audio Surround: 7.1 Channel Housing: Aluminium
Specifications: Converter Type: Format Converter
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 3840 x 2160 (Ultra HD 4K) @ 60hz
Supported Resolutions: 1024 x 768, 1280 x 720, 1920 x 1080, 1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
Connector Type(s): 1 x USB Type-C (24 pin) USB 3.0 Female
System and Cable Requirements: Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
Humidity: 25% to 85% RH Non-Condensing
Operating Temperature: 5 to 35 degree C (41 to 95 degree F)
Storage Temperature: 5 to 35 degree C (41 to 95 degree F)
Ports Spec: Ports: 8
Side A - Connector 1: USB C (MALE)
Side B - Connector 1: (2) HDMI (FEMALE)
Side B - Connector 2: (3) USB A (FEMALE)
Side B - Connector 3: USB C (FEMALE)
Side B - Connector 4: MICRO SD (FEMALE); SD (FEMALE)
Number of Monitors Supported: 2
Video Ports: (2) HDMI (FEMALE)
Video Ports Details: HDCP 1.4; HDCP 2.2
Resolutions Supported : 3840 x 2160 @60Hz (Single); 3840 x 2160 @30Hz (Dual Extended)
Max Supported Video Resolution: 3840 x 2160 @60Hz (Single); 3840 x 2160 @30Hz (Dual Extended)
Extended Mode: Yes
Material of Construction: Aluminum, ABS
Cable Jacket Material: TPE
Cable Jacket Rating: VW-1
Connector Detail: Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B: 1 x HDMI (19 pin) Female Output
Note: Your USB-C port must support DisplayPort over USB-C (DP Alt mode) in order to work with this adapter.
Specifications: Converter Type: Format Converter
Maximum Analog Resolutions: 2048 x 1280 @ 60hz
Maximum Digital Resolutions: 1024 x 768, 1280 x 720, 1920 x 1080, 1920 x 1200, 2048 x 1280
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
Humidity: 25% to 85% RH Non-Condensing
Operating Temperature: 5 to 35 degree C (41 to 95 degree F)
Storage Temperature: 5 to 35 degree C (41 to 95 degree F)
Specifications: Audio: Yes
Chipset ID: NXP - PTN5100 / Pericom - PI3DPX1203
Converter Type: Format Converter
Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 4K (3840 x 2160) @ 60 Hz
Supported Resolutions:
1024 x 768
1280 x 720
1920 x 1080 @ 144hz
1920 x 1200
2560 x 1440
2560 x 1600
3840 x 2160 @ 60Hz
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Connector:
1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
1 x Mini-DisplayPort (20 pin) Female Output
System and Cable Requirements:
Your USB-C device must support DisplayPort over USB-C (DP alt mode) to work with this adapter
This adapter outputs a single-mode Mini DisplayPort signal and will not work with additional video adapters such as Mini DisplayPort to HDMI, Mini DisplayPor...
Specifications: Ports: 1
Input Current: 1.5A
Input Voltage: 100 - 240 AC
Output Current: 3A
Output Voltage:
5V DC
9V DC
12V DC
15V DC
20V DC
Power Consumption (In Watts): 60W
Power Delivery: 60W
Connector A: 1 x NEMA 1-15 Power (North America) Male
Specifications: Connector:
Connector A - 1 x USB-C male
Connector B - 1 x HD15 female / 1 x HDMI female
Max Supported Video Resolution: 4K x 2K (3840 X 2160) @30Hz
HDMI Specification: 1.4
HDCP Specification: 1.4
USB Specification: USB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps)
Audio Specification: 7.1 channel surround sound via HDMI port
Driver Required: No
