Specifications: Weight Capacity:
Display = 6 - 18 lbs. (2.7 - 8.2kg) or up to 25 lbs (11.4kg) with tilt and lift lock-out features engaged
keyboard, mouse and barcode scanner = 4 lbs (1.8kg)
CPU = 50 lbs (22.7kg)
Lift: 25" (64cm)
Tilt: Up +25 degree/ Down -5 degree
Mounting Pattern: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Pan: 360 degree
Rotation: 360 degree
Keyboard Tray Dimensions: 18.6" x 9" (47.2 x 22.8cm)
CPU Dimension: 1-3/8" to 3-3/4" (35 to 95mm) wide; accommodates most small form factor and ultra small form factor CPUs
Monitor Size: Up to 24"
Specifications: Weight Capacity: display = 6-18 lbs (2.7-8.2 kg), worksurface = 10 lbs (4.5 kg), keyboard, mouse and barcode scanner = 4 lbs (1.8 kg), CPU = 50 lbs (22.7 kg)
Lift Range: LCD and keyboard adjusts 20" (51 cm) in tandem with single-motion, LCD adjusts 5" (13 cm) independently, maximum LCD height adjustment = 25" (64 cm)
Monitor up/down tilt: +25 degree /-5 degree
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Worksurface: 22.75"W x 10.6"D (57.8 x 26.9 cm)
Keyboard tray: 18.6"W x 9"D (47.2 x 22.8 cm)
Back-tilt keyboard tray adjustable: 0 degree to -10 degree
CPU Size Range: 1-3/8" to 3-3/4" (35 to 95 mm) wide, accommodates most small form factor and ultra small form factor CPUs
Product Weight: 39.6 lbs (18 kg)
Specifications: Includes stand, CPU strap, buckle cover, VESA monitor mounting kit, cable ties
* Weight Capacity: 6 - 16 lbs. for display; total stand capacity = 37 lbs for combined weight of display, CPU, keyboard and mouse
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Meets tip test requirements of UL Specification 1678
Compatible with most 15" - 24" displays, and most small or ultra small form factor CPUs, notebook computers, and gaming consoles
Maximum CPU size = 14" H x 4" D (36 x 10 cm); minimum CPU size = 7" H x 1.8" D (18 x 4.6 cm). The CPU should be centered on the stand
Motion may be restricted when using 22" - 24" monitors in portrait mode
Removal of lock screw allows portrait to landscape rotation
Mounting Option: Two M4 threaded screw inserts are located at the bottom of ...
Specifications: Weight Capacity: 6–16 lbs (2.7–7.2 kg) for display; total stand capacity = 37 lbs (16.7 kg) for combined weight of display, CPU, keyboard and mouse
Motion may be restricted when using 22"–24" monitors in portrait mode
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Five-inch (13 cm) height adjustment ergonomically accommodates average range of users
Meets tip test requirements of UL Specification 1678 + Removal of lock screw allows portrait to landscape rotation (90°)
Compatible with most 15"–24" displays, and most small or ultra small form factor CPUs.
Maximum CPU size = 15"W x 14"H x 4.5"D (38 x 35.6 x 11.4 cm); minimum CPU size = 7"W x 7"H x 2"D (18 x 18 x 5.1 cm). Provided rubber spacer must be used to accommodate CPU depths of less than 3" (7.6 cm)
Moun...
