Dimensions: 104 x 40 x 15 mm / 4.1 x 1.6 x 0.6 inches
Specifications: M.2 size: Length support 2230, 2242, 2260, 2280
M.2 Support: M.2 NVMe with "M" Key Only
USB cable connector: USB-C to USB-C
USB cable length: 300mm / 11.8 inches
Specifications: Chipset ID: JMicron - JMS580
Drive Size: 22mm - M.2 SATA
Supported Drive Height(s): 2242 / 2260 / 2280
Compatible Drive Types: M.2 (SATA, B-Key, NGFF) / M.2 SATA (NGFF, B+M-Key)
Maximum Data Transfer Rate: 6 Gbps
MTBF: 50,000 hours
TRIM Support:Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
Drive Connectors: 1 - M.2 (SATA, B-Key, NGFF) Receptacle
Host Connectors: 1 - USB Type-C (24 pin) USB 3.1 (10Gbps) Male
Note:
Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
Windows 7 and earlier Windows versions do not support TRIM with USB to SATA devices.
Specifications: M.2 SSD Support: M.2 (NGFF), B Key or B+M Key
Internal Interface: 1 x M.2 (NGFF, B-Key)
External Interface: Standard USB 3.0 Micro-B
Computer Interface: USB Type A required
USB cable connector: USB 3.0 Micro-B and USB 3.0 Type-A
USB cable length: 475mm / 18 inches
Specifications: Form Factor
Thunderbolt rackmount enclosure
External Connectors
Two Thunderbolt ports
Power (C14-type)
Internal Connector
6-pin Mini-Fit Jr (same type as on legacy Mac Pro motherboard; provides up to 75W of power for PCIe cards that require supplemental power)
Expansion Slots (Facing Rear, Top to Bottom)
One x8 mechanical (x8 electrical) PCIe 3.0
One x16 mechanical (x8 electrical) PCIe 3.0
One x8 mechanical (x4 electrical) PCIe 3.0
PCIe Cards Supported
Three full-length, full-height, single-width PCIe cards or
One full-length, full-height, double-width PCIe card, plus one single-width card
