Changer Type: Mini DisplayPort to VGA / DVI / HDMI
Color: White
Specifications: Mini DP to VGA/DVI/HDMI adapter connects your Mini DisplayPort or Thunderbolt 1/2 laptop or tablet to a VGA, DVI or HDMI display.
Multiple video outputs connect to most displays-no more carrying multiple adapters
Delivers high-definition picture quality at resolutions up to 1920 x 1200, including 1080p
Compact unit fits easily into briefcase or laptop bag for instant use anywhere
Plug-and-play operation with no software required for easy, immediate installation
Passive adapter requires connected computer to have DP++ port for signal pass-through
Specifications: Chipset: Analogix ANX9832
Compliant with DisplayPort 1.1a receiver
Configurable 1 or 2 lane operation
Supports 1.62 and 2.7 Gbps data rates
Supports Down Spread Spectrum (SSC)
Display modes:
PC: VGA, SVGA, XGA, SXGA, UXGA & WUXGA display modes
HDTV: 480i, 576i, 480p, 576p, 1080i and 1080p
Product:
Overall Length: 8.85" +/- 0.6" (225mm +/- 15mm)
Weight: 0.08 lbs
Color: White
Material: Plastic
Connectors: 20-Pin Mini DisplayPort (male) to 15-pin VGA (female)
Mini DisplayPort connector housing (L x W x H): 1.06" x 0.43" x 0.35" (27 x 11 x 9 mm)
VGA connector housing (L x W x H): 1.77" x 1.77" x 0.59" (45 x 45 x 15 mm)
Environmental conditions:
Operating temperature: 32 to 140 degrees F
Storage temperature: 14 to 158 degrees F
Humidity: < 85% non-condensing
Certifications/ Standards: FCC, CE, RoHS...
Changer Type: Mini DisplayPort 1.2 to VGA/DVI/HDMI All-in-One Converter Adapter
Color: Black
Specifications: Mini DP to HDMI/VGA/DVI adapter connects your Mini DP or Thunderbolt 1/2 laptop to a VGA, DVI or HDMI display.
Multiple video outputs connect to most displays—no more carrying multiple adapters
HDMI port delivers UHD quality at resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz
DVI and VGA ports support 1080p for sharp high-definition video presentations
Compact unit fits easily into briefcase or laptop bag for instant use anywhere
Plug-and-play operation with no software required for easy, immediate installation
Specifications: Audio Specifications: HDMI output - 7.1 surround sound
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 x 2160
Supported Resolutions:
HDMI output: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720
DVI and VGA output: 1920 x 1200, 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Humidity: 40%-50%RH
Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage Temperature: -10°C to 80°C (14°F to 176°F)
Connector A: 1 - Mini-DisplayPort (20 pin) Male Input
Changer Type: Mini DisplayPort to VGA Active Adapter
Color: Black
Specifications: Mini DP to VGA adapter connects a VGA monitor to the Mini DisplayPort or Thunderbolt 1/2 output on your laptop or computer.
Continue using your current VGA display without the expense of a new Mini DP monitor
Delivers high-definition picture quality at resolutions up to 1920 x 1200, including 1080p
Active adapter converts single- and dual-mode DP++ output for viewing on VGA display
Compact unit fits easily into briefcase or laptop bag for instant use anywhere
Plug-and-play operation with no software required for easy, immediate installation
