TRENDnet LMR-LW400 Low Loss N-Type Male to N-Type Female Cable, 6m (19.6 ft.), 2.4/5GHz Compatible, TEW-L406- Type: N-Type
- Color: Black
- Connector Number: 2
- Specifications: Construction
Inner Conductor (BCCAI) 0.108 in. (2.74 mm)
Dielectric (Foam PE) 0.285 in. (7.24 mm)
Outer Conductor (Aluminum Tape) 0.291 in. (7.39 mm)
Over Braid (Tinned Copper ) 0.320 in. (8.13 mm)
Jacket (PE) 0.405 in. (10.29mm)
Mechanical
Bend Radius: Installation 1.0 in. (25.4mm)
Bend Radius: Repeated 4.0 in. (101.6 mm)
Bending Moment 0.5 ft-lb (0.68 N-m)
Weight 0.068 lb/ft (0.10 kg/m)
Tensile Strength 160 lb (72.6 kg)
Flat Plate Crush 40 lb/in. (0.71 kg/mm)
Environment
Temperature Operating: -40° C ~ 85°C (-40°F~185°F)
Storage: -70° C ~ 85°C (-94°F~185°F)
Electrical
Cut-off Frequency 16.2 GHz
Velocity of Propagation 85%
Dielectric Constant 1.38
Time Delay 1.20 nS/ft (3.92 nS/m)
Impedance 50 ohms
Capacitance 23.9 pF/ft (78.4 pF/m)
Inductance 0.060 uH/ft ...
- Model #: TEW-L406
