Specifications: Requirements:
For PC Users
Windows XP, Windows Vista, Windows 7, Windows 8/8.1, 10
Available USB 2.0 port
Chrome Book
Linux, Unix and other USB supported systems*
*Additional drivers and support may be needed
For MAC Users
Mac 8.6 or greater. Requires OS X for USB 2.0 support
Available USB 2.0 port
Specifications: System Requirements: Computer or other device with available USB port and Windows XP or later, Mac OS X 10.3 and later, or Linux operating system
Specifications: Dell Harmony: A7446404
TechData Dis: 11200138
ASI: 81667
D and H: ICUSBAUDIO
Ingram Micro USA: M03004
Synnex US: STA-ICUSBAUDIO
Chipset ID: C-Media - CM108AH
OS Compatibility:
Windows 2000, XP, Vista, 7, 8, 8.1, 10
Windows Server 2012, 2012 R2, 2016
Mac OS X 10.6 to 10.13
Linux 3.5 to 4.11.x LTS Versions Only
Note: The ICUSBAUDIO supports mono, and not stereo microphone input
Specifications: Hardware
Ports: 4
Bus Type: USB 2.0
Port Style: External Hub
Chipset ID: FTDI FT2232H
Connector(s)
External Ports: 1 - USB B (4 pin) Female
4 - DB-9 (9 pin; D-Sub) Male
Performance
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 921.6Kbps
Serial Protocol: RS-232
Data Bits: 7, 8
FIFO: 4096 byte Transmit and Receive
Parity: Odd, Even, Mark, Space, None
Stop Bits: 1, 2
Software
OS Compatibility: Windows 8 (32/63bit), 7 (32/64), Vista(32/64), XP(32/64), 2000, CE
Windows Server 2008 R2, 2003(32/64), 2000
Mac OS 10.x
Linux 2.4.x/ 2.6.x
Physical Characteristics
Enclosure Type: Steel
Color: Black
Product Length: 5.9 in [150 mm]
Product Width: 2.6 in [66.5 mm]
Product Height: 1 in [26 mm]
Product Weight: 15.9 oz [450 g]
Indicators
LED Indicators: 4 - Each, Tx/Rx Activity indicators
Powe...
Specifications: Humidity: 0~65% RH
Operating Temperature: 0 to 60 degree C
Storage Temperature: -20 to 80 degree C
FIFO: 512 Bytes
Flow Control: None, Xon/Xoff, RTS/CTS, DTR/DSR
Max Baud Rate:921.6 Kbps
MTBF:30,000 Hours
OS Compatibility:
Windows 7, 8.1, 10
Windows Server 2008 R2, 2012 R2, 2016
Mac OS X 10.11 and 10.12
Linux 2.6.x to 4.4.x LTS Versions only
Specifications: Computer Connections
Direct 2
Port Selection Remote control selector button
LEDs
Port Status White
Switches
Port Selection: Remote Console Selector Button x 1
Operating Temperature: 32 ~ 104F (0 ~ 40C)
Storage Temperature: -4 ~ 140F (-20 ~ 60C)
Humidity: 0~80%
Housing
Case: Plastic
Cable Length: 54" (137.16cm)
Cable Type : USB 3.0 Type B to A x 4
Power Consumption: DC 5V, 1.43W
Operating System Support: Windows Vista, Windows 7, Windows 8, Windows 8.1, Mac OS X 10.3+, Chrome OS, Linux-based systems
Specifications: Color: Gray
Humidity: 5% to 95% RH
Interface/Bridge: USB 2.0
Number of Ports: 2
Operating Temperature: 0°C to 55°C (32°F to 131°F)
Storage Temperature: -20°C to 85°C (-4°F to 185°F)
Max Baud Rate: 921.6Kbps
Data Bits: 7, 8
Stop Bits: 1 and 2
Parity: Odd, Even, Mark, Space, and None
Flow Control: Xon/Xoff, Hardware, and None
LED Indicators: 1 - Red - Power LED
Bus Type: USB 2.0
Connector Types: 1 - DB9 Male
Connector Types: 1 - Terminal Block
Connector Types: 1 - USB B Female
Power Adapter Included: Optional
Output Voltage: 5 DC
Output Current: 385mA
Center Tip Polarity: Positive
Plug Type: B
OS Compatibility:
Windows 98SE/ ME/ 2000/ XP(32/64bit)/ 2003(32/64bit)/ Vista(32/64bit)/ Server 2008(32/64bit)/ 7(32/64bit)/ Server 2008 R2, Mac 9.8/OS X, Linux 2.4.x and up;
Wind...
Specifications: Computer Connections
Direct 2
Port Selection Remote control selector button
LEDs
Port Status White
Switches
Port Selection: Remote Console Selector Button x 1
Operating Temperature: 32 ~ 104F (0 ~ 40C)
Storage Temperature: -4 ~ 140F (-20 ~ 60C)
Humidity: 0~80%
Housing
Case: Plastic
Cable Length: 54" (137.16cm)
Cable Type : USB 3.0 Type B to A x 4
Power Consumption: DC 5V, 1.43W
Operating System Support: Windows Vista®, Windows® 7, Windows® 8, Windows® 8.1, Mac OS X 10.3+, Chrome OS™, Linux-based systems
Specifications: Humidity: 5~85% RH
Operating Temperature: -10 to 80 degree C
Storage Temperature: -20 to 100 degree C
FIFO: 512 Bytes
Flow Control: None, Xon/Xoff, RTS/CTS, DTR/DSR
Max Baud Rate:921.6 Kbps
MTBF:30,000 Hours
OS Compatibility:
Windows 7, 8.1, 10
Windows Server 2008 R2, 2012 R2, 2016
Mac OS X 10.11 and 10.12
Linux 2.6.x to 4.4.x LTS Versions only
