Media Type: Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands
Media sizes supported: Maximum Label Length: 39.0 in./991 mm
Maximum Label and Media Width: 4.65 in./118 mm
Media Roll Size: 5.00 in./127 mm outer diameter Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in. (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm) and 3.0 in. (76.2 mm) using optional adapters
Thickness: 0.003 in./0.08 mm - 0.012 in./0.305 mm (tear-off mode only)
Fonts Included: Character fonts: Standard bitmapped Zebra fonts: A, B, C, D, E (OCR-B), F,
G, H (OCR-A), GS, P, Q, R, S, T, U, V & Ø Smooth font (CG Triumvirate™ Bold
Condensed)
Supports user-defined fonts and graphics — including custom logos
Bitmap fonts are expandable up to 10 times, height- and width-independent.
Fonts E and H (OCR-B and OCR-A), however, are not considered in spec
when expanded
Smooth-scalable font Ø (CG Triumvirate Bold Condensed) is expandable dotby-dot, height-and width-independent, while maintaining edges to a max.
1500 x 1500 dots
Barcode Type: Linear Barcodes
Codabar, Code 11, Code 39, Code 93, Code 128,
EAN-8, EAN-13, EAN-14, GS1 DataBar™ (formerly RSS),
Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI,
Plessey, Postnet, Standard 2-of-5, UPC-A, UPC-E,
UPC-A and UPC-E with EAN 2 or 5 digit extension...
