Specifications: Bus Type USB: 3.1 Gen 2
Chipset ID: ASMedia - ASM1352R
Compatible Drive Types: M.2 (NGFF, B-Key)
Drive Installation: Fixed
Interface: USB 3.1 Gen 2
Number of Drives: 2
Supported Drive Height(s): 2230, 2242, 2260, 2280
General Specifications Not compatible with PCI-Express M.2 SSDs
Maximum Data Transfer Rate: 10 Gbps
MTBF: 35,000
Port Multiplier: Yes
Trim Supported: Yes
Type and Rate: USB 3.1 Gen 2 - 10 Gbit/s, SATA III (6 Gbps)
UASP Support: Yes
LED Indicators: 2 - Read / Write (green), 2 - Error / Rebuilt (red)
Specifications: Chipset ID: ASMedia - ASM1092R
Compatible Drive Types (Type and Rate): M.2 (NGFF; B-Key)
Drive Installation: Fixed
Drive Size: 22m - M.2 NGFF
Interface : SATA
Number of Drives: 2
Supported Drive Height(s):
2230
2242
2260
2280
Maximum Data Transfer Rate: 6Gbps
MTBF: 500000
Port Multiplier: Yes
RAID: Yes
Supported RAID Modes:
RAID 0 (Striped Disks)
RAID 1 (Mirrored Disks)
JBOD - (Just a Bunch of Disks)
BIG (Spanning or Concatenation)
Type and Rate: SATA III (6 Gbps)
Drive Connectors: 1 - SATA Data & Power Combo (7+15 pin) Female
Host Connectors: 2 - M.2 (NGFF; B-Key) Male
OS Compatibility: OS independent; No software or drivers required
LED Indicators: 2 - Drive Error
Humidity: 5% ~ 95% RH
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Storage Temperature: -10°C to 85°C (...
