Specifications: Chipset ID: STDP4320
Output Signal: DisplayPort
Ports: 3
Maximum Digital Resolutions: Up to 4K
Wide Screen Supported: Yes
OS Compatibility: Windows 10 (32/64), Windows 8/8.1 (32/64), Windows 7(32/64)
Center Tip Polarity: Positive
Input Current: 0.5 A
Input Voltage: 110V-240V AC
Output Current: 3A
Output Voltage: 5 DC
Plug Type: N
Power Consumption (In Watts): 15
Power Source: AC Adapter Included
Operating Temperature: 0 to 45 degree C (32 to 113 degree F)
Storage Temperature: -20 to 70 degree C (-4 to 158 degree F)
Enclosure Type: Plastic
Connector A: 1 x DisplayPort (20 pin) Latching Male
Specifications: Audio Specifications: HDMI output - 7.1 surround sound; DVI output - 2-channel stereo audio
General Specifications: Only one video output is supported on the video adapter at a time. If multiple connections are made, only one of the outputs will function.
Maximum Analog Resolutions: 1920 x 1200
Maximum Digital Resolutions: 3840 × 2160
Maximum Power Delivery Support: None
Supported Resolutions: HDMI output: 3840 x 2160 (@ 30 Hz), 2560 x 1600, 2048 x 1280 (@ 60 Hz), 1920 x 1200, 1920 x 1080, 1280 x 720; VGA and DVI output: 1920 x 1200 (@ 60 Hz), 1920 x 1080, 1280 x 720
Video Revision: DisplayPort 1.2
Wide Screen Supported: Yes
Output Connector: 1 x HDMI (19 pin) Female Output
1 x DVI-I (29 pin) Female Output
1 x VGA (15 pin, High Density D-Sub) Female Output
