Specifications: Description: WorkFit-C Sit-Stand Workstation for Two LCD Monitors, Dual, with Mobile Cart Base (black/grey)
Includes cart, two (2) LCD mounts, crossbar, integrated worksurface, large stowable keyboard tray, cable storage box, CPU holder, four dual casters (two locking), hand-brake system
**** Maximum outside width of each display = 21.25" (54 cm)
* Weight Capacity: Maximum load on height-adjustment assembly = 32.5 lbs (14.7 kg). Includes weight of displays and keyboard in addition to contents on Worksurface and in Cable Storage Box. LCD mount capacity = 6-14 lbs (2.7-6.3 kg) each, 12-28 lbs (5.5-12.7 kg) total
*** Lift Range: LCDs/keyboard/worksurface adjust 20" (51 cm) in tandem; LCDs adjust 5" (13 cm) independently; maximum LCD height adjustment = 25" (63 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 1...
Specifications: Recommended Use: LCD display / keyboard / mouse / CPU
Recommended Display Size: 30"
Flat Panel Mount Interface: 100 x 100 mm, 75 x 75 mm, 200 x 200 mm, 400 x 200 mm
Max Load Weight 28 lbs
Color: Gray, black
Adjustable height, rotating, tilt, locking casters, cable box
Specifications: Weight Capacity: display = 6-18 lbs (2.7-8.2 kg), worksurface = 10 lbs (4.5 kg), keyboard, mouse and barcode scanner = 4 lbs (1.8 kg), CPU = 50 lbs (22.7 kg)
Lift Range: LCD and keyboard adjusts 20" (51 cm) in tandem with single-motion, LCD adjusts 5" (13 cm) independently, maximum LCD height adjustment = 25" (64 cm)
Monitor up/down tilt: +25 degree /-5 degree
Mounting Standards: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Worksurface: 22.75"W x 10.6"D (57.8 x 26.9 cm)
Keyboard tray: 18.6"W x 9"D (47.2 x 22.8 cm)
Back-tilt keyboard tray adjustable: 0 degree to -10 degree
CPU Size Range: 1-3/8" to 3-3/4" (35 to 95 mm) wide, accommodates most small form factor and ultra small form factor CPUs
Product Weight: 39.6 lbs (18 kg)
Specifications: Includes height-adjustment column, desk clamp, crossbar, two (2) LCD pivots, worksurface/keyboard, one (1) USB extension cable, two (2) cable wraps
NOTE: Extra-long cables are required to span between standing and sitting heights
Optimized for desks that are 30"-36" deep (76-91 cm): on desks shorter than 30", worksurface will extend beyond desktop edge; on desks deeper than 36", worksurface will not extend to desktop edge
Worksurface Dimensions: 29.5" x 21.8" (75 x 55.4 cm)
Maximum outside width of display is 24.5" (62 cm) when display is 2" (5 cm) thick. Accommodates most displays with screen-size up to 24" as well as some displays with screens as large as 26". Actual allowable width of displays will vary depending on display thickness
Weight Capacity: Maximum total load on height-adjustment assembly = 25 ...
Specifications: Device Supported: CPU, Flat Panel Display, Keyboard, Mouse
Maximum Load Capacity: 25.00 lb
Maximum Screen Size Supported: 42"
Color: Black
VESA Mount Compatible: Yes
VESA Mount Standard: 75 x 75, 100 x 100, 200 x 100, 200 x 200, 400 x 200, 400 x 300, 400 x 400
Material: Aluminum
Weight (Approximate): 39.00 lb
Type: WorkFit C-Mod, Single Display Sit-Stand Workstation
Specifications: LCD Size: = 22"
Capacity: 5–18 lbs/2.3–8.1 kg
Lift: 25"/63 cm
Tilt: 25°
Rotation: 360° P/L
VESA: MIS-D
Includes cart, LCD pivot, integrated worksurface, keyboard tray with left/right mouse tray, wrist rest, mouse holder, cable storage box, CPU holder, four dual casters (two locking)
Lift Range: LCD/keyboard/worksurface adjusts 20" (51 cm) in tandem; LCD adjusts 5" (13 cm) independently; maximum LCD height adjustment = 25" (63 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Constant Force (CF) lift-and-pivot motion technology
CPUs attach safely to rear of cart with CPU Holder. Accommodates CPUs from 12"H x 3"D to 18"H x 8.5"D (30 x 8 cm to 46 x 22 cm)
CPU Holder capacity = 40 lbs (18 kg)
Ergonomic negative-t...
Specifications: Compatibility: <=24" LCD
Weight Capacity: 5-30 lbs(2.3-13.6 kg)
Lift: 9"(22.9 cm)
Tilt: 10°
VESA: MIS-D
Additional Information:
Negative-tilt keyboard tray is adjustable 0° to -10°
Maximum Monitor Weight = 25 lbs (11.3 kg)
Monitor thickness greater than 3" (7.6 cm) may decrease capacity
Integrated Cable Management System can be Configured on Either Side
Mounting Standards: VESA FDMI MIS-D, 100/75 (hole pattern: 100 x 100 mm & 75 x 75 mm)
Package Contents:
StyleView 60-593-195 Vertical Mount Lift
Mouse Pad
Wrist Rest
Mouse Pouch
Specifications: LCD Size: <=24"
Capacity: 8-33 lbs
Mounting Standards: VESA FDMI MIS-D, 100/75 (hole pattern: 100 x 100 mm & 75 x 75 mm)
Monitor pans left/right up to 50° (varies per size of monitor)
Fold-down keyboard with built-in mouse pad surface
Keyboard tray extends out up to 5" (12.7 cm) inches when in use
Keyboard tray pans left/right up to 120°
Scanner and mouse holder integrated into the keyboard tray
Back-tilt keyboard tray adjustable (0 to -10 degrees)
Integrated cable management system can be configured on either side
Easy-to-clean exterior
Specifications: Includes height-adjustment column, desk clamp, LCD pivot, worksurface/keyboard, one (1) USB extension cable, one (1) cable wrap
NOTE: Extra-long cables are required to span between standing and sitting heights
Optimized for desks that are 30"-36" deep (76-91 cm): on desks shorter than 30", worksurface will extend beyond desktop edge; on desks deeper than 36", worksurface will not extend to desktop edge
Worksurface Dimensions: 29.5" x 21.8" (75 x 55.4 cm)
Weight Capacity: Maximum total load on height-adjustment assembly = 16 lbs (7.3 kg). LCD weight = 3-13 lbs (1.3-5.9 kg); worksurface = 5 lbs (2.3 kg)
LCD and keyboard adjust 18" (46 cm) in tandem; LCD adjusts 5" (13 cm) independently; maximum LCD height adjustment = 23" (58 cm)
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 ...
Specifications: Includes stand, CPU strap, buckle cover, VESA monitor mounting kit, cable ties
* Weight Capacity: 6 - 16 lbs. for display; total stand capacity = 37 lbs for combined weight of display, CPU, keyboard and mouse
Mounting Standards: VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm)
Meets tip test requirements of UL Specification 1678
Compatible with most 15" - 24" displays, and most small or ultra small form factor CPUs, notebook computers, and gaming consoles
Maximum CPU size = 14" H x 4" D (36 x 10 cm); minimum CPU size = 7" H x 1.8" D (18 x 4.6 cm). The CPU should be centered on the stand
Motion may be restricted when using 22" - 24" monitors in portrait mode
Removal of lock screw allows portrait to landscape rotation
Mounting Option: Two M4 threaded screw inserts are located at the bottom of ...
Specifications: Weight Capacity:
Display = 6 - 18 lbs. (2.7 - 8.2kg) or up to 25 lbs (11.4kg) with tilt and lift lock-out features engaged
keyboard, mouse and barcode scanner = 4 lbs (1.8kg)
CPU = 50 lbs (22.7kg)
Lift: 25" (64cm)
Tilt: Up +25 degree/ Down -5 degree
Mounting Pattern: VESA FDMI, MIS-D, 75/100, C (hole patterns = 100 x 100 mm and 75 x 75 mm)
Pan: 360 degree
Rotation: 360 degree
Keyboard Tray Dimensions: 18.6" x 9" (47.2 x 22.8cm)
CPU Dimension: 1-3/8" to 3-3/4" (35 to 95mm) wide; accommodates most small form factor and ultra small form factor CPUs
Monitor Size: Up to 24"
