SUPERMICRO C7Z87-OCE LGA 1150 Intel Z87 HDMI SATA 6Gb/s USB 3.0 ATX Intel Motherboard
See more "supermicro motherboard"
Check more best sellers of "Intel Motherboards"
Check more lowest price of "Intel Motherboards"
In stock.
Ships from China.
Fees for brokerage and duty included in price.
- Intel Z87
- 4th-Gen Intel Core i7 / i5/ i3 (LGA1150)
- DDR3 1600 up to 3000/
+
+
Specs
Reviews
Learn more about the Supermicro C7Z87-OCE
| Brand | SUPERMICRO |
|---|---|
| Model | C7Z87-OCE |
| CPU Socket Type | LGA 1150 |
|---|---|
| CPU Type | Intel 4th Gen Core i3/i5/i7 Processor |
| Chipset | Intel Z87 |
|---|
| Onboard Video Chipset | Supported only by CPU with integrated graphic |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 1600 up to 3000 |
| PCI Express 3.0 x16 | 3 x PCIe3.0 x16(16/NA/NA or 8/8/NA or 8/4/4) |
|---|---|
| PCI Express x4 | 3 x PCIe2.0 x4 running at x1 |
| SATA 6Gb/s | 8 x SATA 6Gb/s(6 by chipset, 2 by ASM1061) |
|---|---|
| SATA RAID | 0/1/5/10 |
| Audio Chipset | Realtek ALC1150 |
|---|---|
| Audio Channels | 7.1 Channels |
| LAN Chipset | Intel I217-V |
|---|---|
| Second LAN Chipset | Intel I210-AT |
| Max LAN Speed | 2 x 1Gbps |
| Video Ports | D-Sub + DVI |
|---|---|
| HDMI | 1 x HDMI |
| USB 3.0 | 4 x USB 3.0 |
| USB 1.1/2.0 | 2 x USB 2.0 |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 5 Ports |
| Onboard USB | 4 x USB 3.0 + 4 x USB 2.0 |
|---|
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | Server Level Power Design -Digital PWM controller, One controller one phase -6+2 Phases Power design , support up to 300W Simplified HW Debugging Minimize System Downtime -Dual Bios Boot Block -Bios Keeper Boost Working Productivities -Support up to 3 independent display(triple Display) -VGA, Display port, DVI and HDMI are all supported. Ultimate Gaming Experience -Support 4K resolution display for one or multi-display -Support up to 2 Collage display modes |
|---|
| Package Contents | TA9745 |
|---|
| Date First Available | April 01, 2021 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 3 years
- Read full details
Return Policies
- Return for refund within: 30 days
- Return for replacement within: 60 days
- This item is covered by Bill's markerplace Return Policy
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-408-503-8000
- Support Website
- View other products from Supermicro
