ASRock P67 EXTREME6 (B3) LGA 1155 Intel P67 SATA 6Gb/s USB 3.0 ATX Intel Motherboard

OUT OF STOCK.
Fees for brokerage and duty included in price.
  • Intel P67
  • Core i7 / i5 / i3 (LGA1155)
  • DDR3 2133(OC)/1866(OC)/1600/1333/1066
Specs
Reviews

Learn more about the ASRock P67 EXTREME6 (B3)

Model
Brand ASRock
Model P67 EXTREME6 (B3)
Supported CPU
CPU Socket Type LGA 1155
CPU Type Core i7 / i5 / i3 (LGA1155)
Supported CPU Technologies Supports Intel Turbo Boost 2.0 Technology
Supports Intel K-Series unlocked CPU
Supports Hyper-Threading Technology
Chipsets
Chipset Intel P67
Onboard Video
Onboard Video Chipset None
Memory
Number of Memory Slots 4x240pin
Memory Standard DDR3 2133(OC)/1866(OC)/1600/1333/1066
Maximum Memory Supported 32GB
Channel Supported Dual Channel
Expansion Slots
PCI Express 2.0 x16 3 x PCI Express 2.0 x16 slots (PCIE2/PCIE4: single at x16 or dual at x8/x8 mode; PCIE5: x4 mode)
PCI Express x1 2 x PCI Express x1
PCI Slots 2 x PCI Slots
Storage Devices
SATA 3Gb/s 4 x SATA 3Gb/s
SATA 6Gb/s 2 x SATA3 6.0 Gb/s by P67
4 x SATA3 6.0 Gb/s by Marvell SE9120 (SATA3_M4 connector is shared with eSATA3 port)
SATA RAID 2 x SATA3 6.0 Gb/s: RAID (RAID 0, RAID 1, RAID 10, RAID 5 and Intel Rapid Storage), NCQ, AHCI and "Hot Plug" functions by P67
4 x SATA2 3.0 Gb/s: RAID (RAID 0, RAID 1, RAID 10, RAID 5 and Intel Rapid Storage), NCQ, AHCI and "Hot Plug" functions by P67
Onboard Audio
Audio Chipset Realtek ALC892
Audio Channels 8 Channels
Onboard LAN
LAN Chipset Realtek 8111E
Second LAN Chipset Realtek 8111E
Max LAN Speed Dual 10/100/1000Mbps
Rear Panel Ports
PS/2 2
USB 3.0 4 x USB 3.0
USB 1.1/2.0 4 x USB 2.0
IEEE 1394 1 x IEEE 1394
eSATA 1 x eSATA 6Gb/s
S/PDIF Out 1 x Optical, 1 x Coaxial
Audio Ports 6 Ports
Internal I/O Connectors
Onboard USB 2 x USB 3.0 + 8 x USB 2.0
Onboard 1394 1 x 1394
Physical Spec
Form Factor ATX
Dimensions (W x L) 12.0" x 9.6"
Power Pin 24 Pin
Features
Features Premium Gold Caps (2.5 x longer life time), 100% Japan-made high-quality Conductive Polymer Capacitors

Digi Power, Advanced V16 + 2 Power Phase Design

Supports Intel K-Series unlocked CPU

Supports Dual Channel DDR3 2133(OC)

Supports ATI Quad CrossFireX, 3-Way CrossFireX and CrossFireX

Supports NVIDIA Quad SLI and SLI

Dual PCIE GLAN with Teaming function

2 x Front USB 3.0 ports, 4 x Rear USB 3.0 ports, 6 x SATA3 connectors, 1 x eSATA3 connector, 2 x IEEE 1394 ports

7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec), THX TruStudio Pro and Premium Blu-ray audio support

ErP/EuP Ready

Combo Cooler Option (C.C.O.)

Dr. Debug, Smart Swith Design: Power/Reset/Clear CMOS Switch with LED

Supports ASRock Extreme Tuning Utility (AXTU), Instant Boot, Instant Flash, Good Night LED, Multi-Speed Fan Control, AIWI, APP Charger, SmartView
Additional Information
Date First Available March 11, 2011
