LIS3DSH 3-axis Accelerometer Module High-Resolution 1.71V to 3.6V ±2g ±4g ±6g ±8g ±16g Dynamically Selectable Full Scale 3.125 Hz to 1.6 kHz 16-bit Data Output I2C SPI Output Interface

NOYITO LIS3DSH-master Document https: //1drv. ms/u/c/4a0865b22350d05c/IQBc0FAjsmUIIIBKswAAAAAAATm02IbcEKAcufRt6Zk552s? e=qQneGc Description The LIS3DSH is an ultra-low-power highperformance three-axis linear accelerometer belonging to the nano family with an embedded state machine that can be programmed to implement autonomous applications. The LIS3DSH has dynamically selectable full scales of ±2g ±4g ±6g ±8g ±16g and is capable of measuring accelerations with output data rates from 3.125 Hz to 1.6 kHz. The self-test capability allows the user to check the functioning of the sensor in the final application. The device can be configured to generate interrupt signals activated by user-defined motion patterns. The LIS3DSH has an integrated first-in, first-out (FIFO) buffer allowing the user to store data in order to limit intervention by the host processor. Features Wide supply voltage, 1.71 V to 3.6 V Independent IOs supply ( 1.8 V) and supply voltage compatible Ultra-low power consumption ±2g ±4g ±6g ±8g ±16g dynamically selectable full scale I2C/SPI digital output interface 16-bit data output Programmable embedded state machines Embedded temperature sensor Embedded self-test Embedded FIFO 10000 g high shock survivability Applications Motion-controlled user interface Gaming and virtual reality Pedometers Intelligent power saving for handheld devices Display orientation Click/double-click recognition Impact recognition and logging Vibration monitoring and compensation
Package Included: 1pcs NOYITO LIS3DSH Three-axis Accelerometer Module
