AEDR-8300 Reflective 2-Channel Encoder Optical Encoders Module

AEDR-8300 Document download https: //1drv. ms/b/c/4a0865b22350d05c/IQBc0FAjsmUIIIBKowAAAAAAAaJcmNjCEaFCIGDa7VsuDWI? e=8tqD4l Description The AEDR-8300 series is the smallest optical encoder employing reflective technology for motion control purposes. The encoder houses an LED light source and a photo-detecting circuitry in a single package. The AEDS-8300 series offers options of either single channel or two-channel quadrature digital outputs. Being TTL compatible, the outputs of the AEDR-8300 series can be interfaced directly with most of the signal processing circuitries. Hence the encoder provides great design-in flexibility and easy integration into existing systems. Features Reflective technology Surface mount small outline leadless package Single channel incremental output Two channel quadrature outputs for direction sensing TTL compatible output Single 5V supply -20 to 85 absolute operating temperature
Encoding resolution: 75LPI
Package Included: 1pcs NOYITO AEDR-8300 Reflective 2-Channel Encoder Module
