BONAEVER 10-Port PoE Switch Gigabit Ethernet 2 Port Uplink 802.3AT/AF 120W Cat5 Unmanaged Metal Smart Desktop Network Power Over Ethernet Injector

Features: PS-1010GB PoE switch Gigabit provides power and data from a single point, using Power over Ethernet (PoE) over a single Cat-5 cable PoE Injector Gigabit with 8*10/100mbps POE port, 2*10/1000mbps UP-Link port; Each port max. power supply reached 30W. Low heat design, safe and reliable, high stability It can be used for any 10/1000Mbps link and supply industry-standard IEEE 802.3 af power. Advanced auto-sensing algorithm givespower to 802.3 af end devices, In addition, the PoE switch automaticallydetermines PoE requirements, speed, duplex, and cable type usingAutoUplink. Easy to operate and reliable The PoE switch is ideal for powering PoE devices such as IP cameras, WLAN access point, IP phones, office access control systems, and other PD devices and offers a line of high quality products that provide a total solution for Ethernet application in different environments Power Over Ethernet Gigabit Ethernet Injector. Quality is guaranteed. Lifelong technical support 10-Port PoE Switch Gigabit Ethernet 120W 8*10/100mbps POE port, 2*10/100/1000mbps UP-Link port 100m Transmission Distance, 250m after use extend function Compatible with IEEE 802.3AF /AT
Whole Power: 120W(52V 2.8A ) All port supported by MDI/MDIX auto flip and self negotiation Supply 8pcs 10/100Mpbs adaptive high speed forwarding data packetnon-lost port Each port max. power supply reached 30W Low heat design, safe and reliable, high stability
Application: + Wireless Access Point + IP Camera + IP Phone + Computer Networks POE
RJ45 Port: 8*10/100Mbps
Uplink Port: 2*10/100/1000Mbps
DC: 52V/ 2.8A
Bandwidth: 5.6G
Power: Per30W &Whole120W
Data signal port: 1236
Power supply port: 1236(+12 -36)
Distance: 250M
Extend: Yes
Agreement: IEEE 802.3AT /AF
Network Medium: Cat5 (UTP) or more
Network Standards: IEEE 802.3 i 10BASE-T IEEE 802.3 u 100BASE-TX IEEE 802.3 x Flow Control IEEE 802.3 af Power over Ethernet Package List 10 Port 10/1000M POE Switch*1 User Guide*1 Warranty Card*1 Power cable*1 Auto Detects Power Devices Compatible with IEEE 802.3 af/at protocol, PoE switch determines and delivers the exact power supply to your devices with up to 120W power output. Easy to Use Play & Play PoE switch. You just need to connect power cable and the poe devices. Fanless & Silent Operation The PoE switch features with metal case and fanless design that ensures noiseless operation and greater reliability over time.
