289 HD Video Lecture Capture 1080P HDMI / VGA Recorder into USB Disk/Hard Disk Built in Mic for Lecture meeting

289 HD Video Lecture Capture 1080P HDMI / VGA Recorder into USB Disk/Hard Disk Built in Mic for Lecture meeting

With 289 Lecture Capture, just press one button to record digital lesson contents or meeting presentations. with integrated microphone, recording HD lecture combined with voice. It is plug & Play, standalone working no need PC.

The integrated microphone includes noise canceling technology to effectively capture the teacher's voice, and reduce irrelevant background noises for clear, pleasant audio. With one switch button, easily set the gain of microhone for different size room.

Connections

Interface

USB 2.0 Host

Video Input

HDMI, VGA

Audio Input

HDMI, 3.5mm Line In

Video Output

Digital: HDMI (Pass through from HDMI and VGA), VGA (Pass through from VGA)

Audio Output

Digital: HDMI (Pass through from HDMI and VGA), 3.5mm Line Out

Hardware Extra

Codec

Hardware H.264 encoder

User Interface

Record button, 720p/1080p switch button, microphone gain set button, microphone mute button

LED indicator for working status.

Power on/off button

Dimensions

115(L)*115(W)*28.3(H) MM

Weight

185g

Package Contents

Device

289 Lecture Capture

Others

5V DC adaptor, Software CD, Manual

Standards

Storage Media

USB Drive Stick, Portable Hard Disk

Max Capacity: 2T

Note: The exFAT format is not supported.

Resolution

Note: Upscaling is not supported.

Record Format

Video: MP4, Audio: AAC Stereo

Record Quality

Max: 18Mbps@1080P 30fps

Record File

Record Place

Power Supply
