MAIN OVERVIEW FEATURES:
- Storage Capacity: 480 GB
- Maximum Read Transfer Rate: 540 MB/s
- Maximum Write Transfer Rate: 380 MB/s
- Wireless LAN: No
- Drive Interface: SATA
- Drive Interface Standard: SATA/600
- Drive Type: Internal
- Form Factor: 2.5"
- Hot Swappable: Yes
- Height: 0.3"
- Width: 2.8"
- Depth: 3.9"
- Weight (Approximate): 2.47 oz
- Device Supported: Server
- Compatibility: Lenovo
Servers:
- ST550 (7X09/7X10)
- SR530 (7X07/7X08)
- SR550 (7X03/7X04)
- SR630 (7X01/7X02)
- SR650 (7X05/7X06)
- SR950 (7X11/12/13)
- SD530 (7X21)
- SN850 (7X15)
- SN550 (7X16)
- Environmentally Friendly: Yes
- Environmental Certification:
- Limited Warranty: 1 Year
Learn more about the Lenovo 4XB7A08502
Model| Brand | Lenovo |
|---|
| Model | 4XB7A08502 |
|---|
Details| Form Factor | 2.5" |
|---|
| Capacity | 480GB |
|---|
| Memory Components | 3D TLC |
|---|
| Interface | SATA III |
|---|
Performance| Max Sequential Read | Up to 540 MBps |
|---|
| Max Sequential Write | Up to 380 MBps |
|---|
| 4KB Random Read | Up to 93,000 IOPS |
|---|
| 4KB Random Write | Up to 31,000 IOPS |
|---|
| Read Latency | 500 µs |
|---|
| Write Latency | 500 µs |
|---|
| MTBF | 2,000,000 hours |
|---|
Features| Features | Compatibility: Lenovo Servers: ST550 (7X09/7X10) SR530 (7X07/7X08) SR550 (7X03/7X04) SR630 (7X01/7X02) SR650 (7X05/7X06) SR950 (7X11/12/13) SD530 (7X21) SN850 (7X15) SN550 (7X16) Device Supported: Server
Industry standard 2.5-inch or 3.5-inch form factors
Innovative triple-level cell (TLC) 3D NAND technology
Suitable for read-intensive workloads with an endurance of between 0.5 and 0.9 drive writes per day (DWPD) for 5 years
6Gbps SATA host interface
High reliability and enhanced ruggedness
Absence of moving parts to reduce potential failure points in the server
S.M.A.R.T. support
Advanced Encrypting Standard (AES) 256-bit encryption |
|---|
Environmental| Power Consumption (Active) | 4.50W |
|---|
| Max Shock Resistance | 1,500G (Max) at 0.5 ms (non-operating) |
|---|
| Max Vibration Resistance | 3.13 GRMS (5-800 Hz) (non-operating) |
|---|
Dimensions & Weight| Height | 7.00mm |
|---|
| Width | 70.00mm |
|---|
| Depth | 100.00mm |
|---|
| Weight | 70.00g |
|---|
Additional Information| First Listed on Newegg | May 20, 2020 |
|---|
