EPON 1.25G GPON 2.5G XPON(1.25g/2.5g) with FTTH NETWORK wifi modem 10/100/1000M RJ45 FOR OLT switch

EPON=EPON(1.25G)+1 RJ45(10/100/1000M)

GPON=PON(1.25G)+1 RJ45(10/100/1000M)

XPON=PON(1.25G)+GPON(2.5G)+1 RJ45(10/100/1000M)

Product introduce

EPON/GPON/XPON type products fully comply with ITU-T G.984 GPON standards and IEEE802.3ah G/EPON standards. It is operative,

manageable and maintainable at telecommunication level, and can provide high speed data service for customers. It has a PON uplink

port that connects to office end apparatus through optical fiber.

Interface Details

The left to right interfaces are:

PON port: Connect the source OLT device through the fiber optic cable

RJ45 port: Connect to the user side device through twisted pair, the rate is 10/100/1000M adaptive

Reset button: Restore the factory default, use the fine needle to hold the hole for more than 3 seconds, the system will restore

the factory default

Power switch: You can turn off the device to save energy when not in use.

Power interface: connect external power supply

Physical characteristics

Power supply: 12V/500mA

Power consumption: 6W

Temperature:

Working temperature: 0 ~ 55 ° C

Storage temperature: -30 ~ 60 ° C

Relative humidity: 10 to 90% (non-condensing)

EMC / EMI : Compliant with VCCI Class B, FCC Part 15 B

Safety: UL 60950 safety regulations

Lightning protection: ITU-T K.21 standard.

Package Details

The package includes an with opp bag,and an adaptor.

Logo can be printed on the products or the package.

You can have your company information on it on label also.

Adaptor standards can be Europe,America,Asia and so on.

Delivery in carton.

Specifications

Rate
