4+2BZDN PoE Switch Power 4 Ethernet Port 2 Uplink Ethernet Port 1.2Gbps over Ethernet IEEE 802.3 48V 3A for Cameras Networking

DescriptionThis 4+2BZDN PoE Switch Power with 4 Ethernet Port 2 Uplink Ethernet Port 1.2Gbps over Ethernet IEEE 802.3 48V 3A,provides an easier installation way for PoE devices, such as IP cameras, wireless AP, Access control system.Features4+2BZDN PoE Switch Power can detect your PoE devices according to PoE standard.Therefore the PoE switch will compatible well with their PoE devices.4 Ethernet Port and 2 Uplink Ethernet Port can be connected with different equipment, one button to achieve intelligent run.The max transmission distance is 200 meters with 1.2Gbps. Ideally, shorter cable would reduce the power degradation overthe cables with high quality cables also can reduce power loss.Plug and play design make the installation super simple, users do not need any configuration.This PoE switch is a great choice for IP cameras, wireless AP, VoIP users, access control system, for Most devices which support PoE switch.  4+2 PoE Switch Parameter

Product

4+2 PoE Switch

Model

4+2BZDW

PoE Switch Port

1-4 Port support IEEE 802.3af/at(15.4W/30W) Network Power Supply

SEP Port

Non Support

PoE Switch Output Power

15.4W/30W IEEE802.3af/at

PoE Switch Wire Core

1/2+3/6- Pair4/5+7/8-pairOptional

Port Description

4 Ethernet Port2 Uplink Ethernet Port

PoE Switch Connection Standard

IEEE802.3af/IEEE802.3at

PoE Switch Transmission Distance

200

PoE Switch Type

End Bridging Method

Network Standard

IEEE802.3IEEE802.3uIEEE802.3xIEEE802.3af/at

Network Medium

5 Category and above unshielded twisted pair

Network Signal Distance

transfer120M

Back plan Width

1.2Gbps
