1. Stable Power Supply: The CPU motherboard is equipped with an 8 phase power supply design and a modular large cooling system, ensuring stable and efficient power delivery for optimal performance.
2. Efficient Memory: The motherboard supports DDR4 dual channel memory, allowing for a maximum capacity of up to 128GB . Experience smoothly multitasking and seamless with high speed and ample storage capabilities.
3. High Speed Storage Interface: The motherboard supports NVME PCIE X4 M.2 SSD, offering a theoretical bandwidth of up to 4GB per second. Enjoy fast data transfer speeds and rapid access to your files and applications.
4. Multiple Interface Expansion: With 6 USB 3.0 ports and 6 USB 2.0 ports, the motherboard provides ample interface options to connect various peripherals, satisfying all your external device requirements.
5. Integrated Chipsets: Equipped with integrated sound card or card chipsets, the motherboard set simplifies the connection of sound devices and devices, enhancing convenience in use.
6. Easy Installation: The set includes an E5 2670V CPU and a fan mounting bracket, facilitating quick and easy installation. Get your system up and running smoothly in no time.
Specification:
Item Type: CPU Motherboard Set
Material: PCB
Mainboard Chip:
Integrated Chip Sound Card
Chipset for Intel X99 series
Sound Chip Integrated 6 Channel Sound Chip
Processor Specifications:
CPU Platform: for Intel
CPU Socket: LGA 2011 3
Support CPU: E5 2670V3 x 1 (included)
Supported CPU Type: E5 V3 V4, i7 58xx 68xx series
Memory Apecification
Memory Type: DDR4 2833 2666 2400 2133MHz
Memory Slots: 4 x DDR4 DIMM, up to 128GB, 4 Channels
Expansion Slot:
1 x PCI E X16 Graphics Card Slot
1 x PCI E X4 slot
1 x PCI E X1 Slot
USB3.0 Pins (1 set)
USB2.0 Pin (1 set)
1 x M.2 Port (with PCIE jumper conversion)
1 x M.2 NVME (PCIE)
6 x
