Mean Well XTR-240-48 240W AC/DC 3Ø Input Ultra Slim Industrial DIN Rail Power Supply 48V 5A 48mm Width Ham Radio Computer Uninterruptible Power Supply
- Wide Range Input Voltage: Three-Phase 320 ~ 600Vac wide range input, 600 ~ 700Vac surge input for 1 sec. occasionally (Dual phase operation possible)
- Global Certifications: Global certificates in multi-fields(ITE 62368-1,Industrial 61558-1/-2-16,61010) & Marine DNV,SEMI47,C1D2 HazLoc approved
- Ultra Slim Design: 48mm Ultra slim width optimizes system installation space and fits compact DIN rail configurations
- High Efficiency Performance: High efficiency up to 93.5% and no load power dissipation<2.5W for energy savings and reduced operating costs
- Peak Power Capability: 150% Peak Power capability provides constant current for demanding industrial applications
- Wide Operating Temperature Range: Fanless design with ultra-wide operating temperature range of -40 to +85 (up to +60 at full load)
- Advanced Protection Features: Built-in DC OK and FET (optional), internal PCB coating offers basic moisture and dust protection with comprehensive safety functions
+
+
Overview
Specs
Reviews
Wide Range Input Voltage: Three-Phase 320 ~ 600Vac wide range input, 600 ~ 700Vac surge input for 1 sec. occasionally (Dual phase operation possible)
Global Certifications: Global certificates in multi-fields(ITE 62368-1,Industrial 61558-1/-2-16,61010) & Marine DNV,SEMI47,C1D2 HazLoc approved
Ultra Slim Design: 48mm Ultra slim width optimizes system installation space and fits compact DIN rail configurations
High Efficiency Performance: High efficiency up to 93.5% and no load power dissipation<2.5W for energy savings and reduced operating costs
Peak Power Capability: 150% Peak Power capability provides constant current for demanding industrial applications
Wide Operating Temperature Range: Fanless design with ultra-wide operating temperature range of -40 to +85 (up to +60 at full load)
Advanced Protection Features: Built-in DC OK and FET (optional), internal PCB coating offers basic moisture and dust protection with comprehensive safety functions
Global Certifications: Global certificates in multi-fields(ITE 62368-1,Industrial 61558-1/-2-16,61010) & Marine DNV,SEMI47,C1D2 HazLoc approved
Ultra Slim Design: 48mm Ultra slim width optimizes system installation space and fits compact DIN rail configurations
High Efficiency Performance: High efficiency up to 93.5% and no load power dissipation<2.5W for energy savings and reduced operating costs
Peak Power Capability: 150% Peak Power capability provides constant current for demanding industrial applications
Wide Operating Temperature Range: Fanless design with ultra-wide operating temperature range of -40 to +85 (up to +60 at full load)
Advanced Protection Features: Built-in DC OK and FET (optional), internal PCB coating offers basic moisture and dust protection with comprehensive safety functions
