Mean Well HDR-100-15 92W Ultra Slim Step Shape DIN Rail HDR-100 15V/6.13A

HDR-100 is one economical ultra slim 100W DIN rail power supply series, adapt to be installed on TS-35/7.5orTS-35/15 mounting rails.The body is designed 70mm(4SU) in width, which allows space saving inside thecabinets.The entire series adopts the full range AC input from 85VACto 264VAC(277VACoperational) and conforms to BSEN/EN61000-3-2, the norm theEuropean Union regulates for harmonic current.HDR-100 is designed with plastic housing that it can effectively prevent user from electric hazards.Withworking efficiencyup to 90%, the entire series can operate at the ambient temperature between -30and 7o under air convection.The complete protection functions and relevant certificates for homeautomations and industrial control apparatus (IEC62368-1,UL508,UL62368-1,BS EN/EN61558-2-16)make HDR-100a very competitive power supply solution for household and industrial applications.
