Product Specifications
- Motherboard
- Processor: The i7-8565U CPU, 4 Cores, 1.8GHz, Max 4.6GHz; i7-8559U, 4 Cores, 2.70 GHz, Max 4.50 GHz
- Graphics: integrated UHD; Iris Plus Graphics. support 4K, dual monitor capable
- Chipset: SOC chipset with L3 Cache 8MB
- Memory Slots: 2 SO-DDR4 SDRAM memory slots
- Sound Card: ALC892 chip, providing 6-channel sound
- Drive Interface: 1* mSATA 3.0, 1* NGFF/NVMe with 2280 M.2 Size, 1* SATA 3.0
- Wireless Network: 1*PCI-e for half size wireless network card, 300M 2.4/5.8Ghz dual band Wi-Fi built-in module, dual external antennas enhanced signal 802.11.b/g/n
- System
- The pre-installed operating system is windows 11
- Installing a new system from USB drive, continuously press the button of "F11"
- Entering the interface of BIOS, continuously press the button of "Delete"
- Ports
- Front-Panel: 1 * Power switch button, 1 * LED Power Indicator, 4 * USB 2.0
- Back-Panel: 1 * 12V DC input, 1 * HD port, 1 * DP port, 1 * 82574L Giga LAN Port, 4 * USB 3.0 ports, 2 * Audio In/output, 2* Wi-Fi Connectors for Antennas
Equipped with a Powerful Chip
Mini PC with Core i7-8565U
This micro computer equipped with i7 8th gen cpu, ddr4 ram and ssd storage to make sure it works efficiently. There are sata, msata, m.2 three external storage ports in the motherboard. The m.2 port support ngff and nvme protocol. It can run smoothly in different occasions. Ideal for your home entertainment, business office, education.
For Business & Home
- High Performance: Get mind-blowing work efficiency for all of your office apps, from the daily grind to complex tasks with this mini PC installed with Windows 11 etc.
- Scalable: Different model owns different port for particular purpose. From office to factory, Msecore provides scalable computing solutions for the modern workplace.
- Customizable: According to large or small workloads, customize your solution to meet your needs with memory, storage and operating systems of choice.
The Pros of Micro Computer
- Compared with laptop, you can get better performance with the same money. And the micro computer is also convenient to carry. It is barely a little bigger than a dictionary, easily to put into a backpack.
- Compared with ordinary computer, its fanless design will not cause nosie and can save energy. The compact design and the bracket can decrease sapce occupation. It is a good choice for modern life.
- The Mini PCs can be equipped for monitor, TV, projector and many application occasions because of its small but powerful features.
