Transmission Rate:1200Mbps
Certification:NONE
Origin:CN(Origin)
Kind:External
Type:wireless
Lan Transmission Rate:ETHERNET
Application:Laptop
Wireless Protocol:802.11n
Adapter Socket:USB
Wi-Fi Supported Frequency:2.4G & 5G
Transmission Speed:1200 Mbps
Model Number:LYR0011
Features
Compatible SystemCompatible with Windows (10/ 7/ 8/ XP/Vista); Compatible Mac OS
Lightning Fast speedUpgrades your Wi-Fi Card to 1200Mbps Wi-Fi speeds. Offering 867Mbps over 5GHz or 400Mbps over 2.4GHz for online gaming and HD video streaming with lag experience
USB 3.0 USB 3.0 wifi adapter can transfer data up to 5Gbps, which is backward compatible with USB 2.0 & 1.1
Stable PerformanceWith advanced RTL8812BU chipset amd built-in Antenna for range extended Wi-Fi connection and superior stability on your Desktop, Laptop, wireless adapter offers up to 1200Mbps Wi-Fi speeds in the signal strength, average upload and reading speed.
Wi-Fi Hot Spot You can create a Hot spot with the Soft AP Function for more wifi devices
Product Specification
-Type: AC1300 USB3.0 WiFi Adapter
-Chip: Realtek RTL8812BU
-Frequency Range: 2.412GHz - 2.4835GHz, 5.15 GHz - 5.825 GHz
-Interface: USB3.0
-Max. Downstream Data Rate: 5.8GHz 867Mbps, 2.4GHz 400Mbps
-Antenna Type: Built-in 2dBi antenna
-Network Connectivity: IEEE802.11ac/a/n/g/b
-Security Encryption: WFA, WPA, WPA2, WPS2.0, WAPI
-Support System: Windows XP/Vista/7/8/8.1/10(32-bit/64-bit), Linux2.6X, Mac OS X 10.4-10.12
Dual band WiFi dongle usage instructions
1. You must have a dual band WiFi router with 5G band if you want to have a 5G signal.
2. The adapter's max speed up to 867Mbps just works when you connect to 5G band, otherwise, it will just run at the max speed of 400Mbps with 2.4G.
3. This WiFi adapter will not boost the speed of router, it just transmit the wifi signal.
4. For desktop, if the speed is not ideal, you can try to insert the WiFi adapter into the USB3.0(blue) port of you PC, that may guarantee the fully power supply.
