The new Revo Inspection System features our patented 3-point piezoelectric sensor.
It integrates seamlessly with the Phrozen GO app and connects 24/7 to your mobile phone for timely monitoring.
connected to your mobile phone for timely monitoring.
Receive early notification of a possible failure in the printer and mobile phone (via the Phrozen GO app) when the sensor detects an anomaly during printing.
With a lot of screws and cables to deal with, replacing an LCD can be daunting, but not on the Revo. Rest assured that when it's time to replace the screen, it's quick and easy.
Matching with high precision resin
Lake water ultra-fine resin for smooth and fine model surfaces Designed for high quality 3D printing needs
Highly stable precision double guide rail
Adopting 12mm ball screws and thickening the Z-axis line rail can effectively reduce the vibration amplitude to achieve stable operation in the Z-axis direction, with a minimum print pitch of 10um to achieve a higher precision of the mould.
New Intelligent Assisted Detection
Revo is equipped with a patented three-point strain gauge voltage sensor.
Intimate reminders throughout the entire process, easy to cope with a variety of situations, printing more peace of mind
| Machine System: | Phrozen OS |
|---|---|
| Operating interface: | 5 o'clock touch screen |
| Slicing software: | CHITUBOX V1.9.6 or above (or other software) |
| XY resolution: | 16.8 * 24.8um |
| Machine size: | 353 * 345 * 517mm |
| Printing size: | 223 * 126 * 230mm |
| File transfer mode: | USB |
| Equipped with release mold: | nFep release film |
| Resolution: | 13320-5120 |
| Average printing speed: | 450 layers/hour |
| Slice thickness: | 0.01-0.30mm |
| Built in storage space: | 8GB |
| File format: | CTB/ PRZ |
| Machine weight: | 18 kilograms |
