Partaker Fanless Soft Router 4 Ports, Firewall Micro Appliance, Mini PC Intel J3160 Quad Core, AES-NI, 2GB RAM, 32GB mSATA SSD

Limited time offer, ends 10/10 By Partaker Mini PC's Marketplace

In stock.
Ships from China.
Fees for brokerage and duty included in price. Most customers receive within 4-31 days.
  • 2GB DDR3
  • 4GB DDR3
  • 8GB DDR3
  • 32 GB
  • 64 GB
  • 128 GB
  • 240 GB
  • Intel Celeron J3160 Quad Core 1.6Ghz, Turbo Boost Max 2.48 GHz, AES-NI hardware support
  • Support 1*DDR3L 1600Mhz SODIMM Ram Slot, Max 8G;
  • 2*HDMI+2*USB3.0+4*LAN+1*RJ45 COM+1*Power switch+1*Audio(support audio and mic input);
  • Support 4*Intel i211AT 1000M lan card, support wake on lan;
  • 1*MSATA,1*Mini-PCIE(support WiFi / Bluetooth is optional )(USB channel signal Mini-PCIE WiFi);
  • DC-IN 12V power supply and AC power adapter; Applied in Firewall, Network Server, Network Security, VPN Router etc.
Overview
Specs
Reviews

1.Intel Celeron J3160 Quad Core 1.6Ghz, Turbo Boost Max 2.48 GHz.

2. Support 1*DDR3L 1600Mhz SODIMM Ram Slot, Max 8G;

3. 2*HDMI+2*USB3.0+4*LAN+1*RJ45 COM+1*Power switch+1*Audio(support audio and mic input);

4. Support 4*Intel i210AT 1000M lan card, support wake on lan;

5. 1*MSATA,1*Mini-PCIE(support WiFi / Bluetooth is optional )(USB channel signal Mini-PCIE WiFi);

6. DC-IN 12V power supply and AC power adapter;

7. High-quality Fanless pure aluminum Case;

8. Applied in Firewall, Network Server, Network Security, VPN Router etc.

Model Partaker C4 Fanless Mini PC
CPU Intel Celeron J3160 quad core 1.6GHz, Turbo boost 2.24 GHz Mini PC
Chipset Intel Integrated Chipset
Material of case High quality pure aluminum mini pc case
Memory 1*DDR3L 1600Mhz SODIMM Ram Slot, support max 8G Mini PC
Storage Support 1*MSATA(16G/32G/64G/128G/256G is optional) Pfsense Mini PC
LAN 4*Intel i210AT 10M/100M/1000M Lan
I/O 2*USB3.0, 1*RJ45 COM(support console function),4*RJ45 Lan, 2*HDMI (no sound output), 1*DC-IN 12V,
Built-in I/O 2*Mini-PCIE Connector, 1*Ram Slot Connector
BIOS AMI 64Mbit Flash ROM
Expansion slot 1*Mini-PCIE(support wifi/bt)(USB channel signal Mini-PCIE WiFi); 1*Mini-PCIE(support MSATA)
Mainboard 100*100mm NUC mainboard
Support OS Windows 7, Windows 8, Windows 10, linux, pfsense
Power Supply DC-IN 12V power supply and AC power adapter
Operation Temp -10~60degC
Dimension 115*107.5*39mm

2*HDMI Full HD 1080P Dual Display

Support synchronous and asynchronous dual display.
With Intel HD graphic, give you an extraorinary visual experience.



Aluminum Case, Fanless Design
High quality aluminum case with exquisite cooling teech for quick heat dissipation.
Fanless design for dustproof and no noise during operation, give you a quiet environment.



Power Chip, Superior Strength
Adopt Intel Celeron J3160 quad core 1.6Ghz, stable performance, lower power consumption, faster response.



High-end configuration
Support 1*DDR3L 1600Mhz SODIMM Ram Slot
Support 2*Mini-PCIE, 4*Intel LAN, 2*USB3.0




Small Case, Just one hand can hold
delicate and fashion mini pc case
smaller, neater, easier to use
Size:115*107.5*39mm
