Main Application of USB/HDMI/VGA Conversion Cables:
Connector plating:Gold-plated ,Nickel-plated
Wire core: pure copper
Conductor : Bare copper ,Tinned copper or optional
Over mold:PVC 80Pa ,UL94V-0 Black
Pre mold: PE Low Density
Technical Parameters:
Electrical Characteristics
Connector plating:Gold-plated ,Nickel-plated
Wire core: pure copper
Conductor : Bare copper ,Tinned copper or optional
Over mold:PVC 80Pa ,UL94V-0 Black
Pre mold: PE Low Density
Jacket Color: BLUE,BLACK,WHITE or optional
Mechanical Characteristics
Withdraw Force10N Min
Insertion Force 35N Max
Contact Resistance0.01 OHM Max
Insulation Resistance 10M OHM /300V Min
Hi-Pot : DC 300V 10ms
Compatibility: USB 2.0&USB3.0
Environmental Characteristics
Temperature Range-25°C~ +85°C
