NEW BIG-SIZE Waterproof DC 12V Step-up to 24V 15A 360W Boost Converter Regulator
- Waterproof IP68 Voltage Converter Regulator DC 12V(10V-16V) to DC 24V 15A 360W.
- Protections: Over-load, Over-current, Over-temperature, Short-circuit, Over-voltage.
- Auto-recovery when device is back to normal operating; high transfer efficiency of 95% max..
- Die-cast aluminum shell, anti-shock, and moisture-proof and has stronger durability.Widely used in bus, cmb, large trucks, motor, solar generate electricity, display screen of bus and taxi, car audio device
- Note: It is recommended to use stable DC power for the input power supply If you use the pulsed DC power provided by the generator, please filter it with capacitor before connecting it to the converter. If you use solar panel to supply directly, please note that the open circuit voltage of the solar panel cannot exceed the maximum withstand voltage of the converter. The supply voltage should be within the rated voltage and always leave a certain margin.
+
+
Overview
Specs
Reviews
Product Name: DC 12V to DC 24V 15A Power Converters 360W; Input range: 10-23V DC
Features:
1. 100% full power and stable current output
2. 100% Imported components
3. Wide input voltage from 10-23V DC
4. 100% waterproof and anti-shock protection, Ultra compact size, light weight
5. Industry grade DC12V to DC24V step-up converter, efficiency up to 96%
6. Certificates: CE/RoHS
7. Waterproof level: IP68
8. Die-cast aluminum shell, epoxy potting, Cooling by free air convection,
9. Protections: Over-current, Over-voltage, Over-temperature and Over-load Auto-recovery when device is back to normal operating
10. Non-Isolated Module
11. 1 year warranty, lifetime up to 100,000 hours.
?
Specifications:
Input Rated Voltage: 12V DC
Input Voltage Range: 10-23V DC
Efficiency: 97% (half load); 96% (full load)
Output Voltage: 24V DC
Output Current: 15 Amps
Output Rated Power: 360 Watts
Output Peak Power:
Features:
1. 100% full power and stable current output
2. 100% Imported components
3. Wide input voltage from 10-23V DC
4. 100% waterproof and anti-shock protection, Ultra compact size, light weight
5. Industry grade DC12V to DC24V step-up converter, efficiency up to 96%
6. Certificates: CE/RoHS
7. Waterproof level: IP68
8. Die-cast aluminum shell, epoxy potting, Cooling by free air convection,
9. Protections: Over-current, Over-voltage, Over-temperature and Over-load Auto-recovery when device is back to normal operating
10. Non-Isolated Module
11. 1 year warranty, lifetime up to 100,000 hours.
?
Specifications:
Input Rated Voltage: 12V DC
Input Voltage Range: 10-23V DC
Efficiency: 97% (half load); 96% (full load)
Output Voltage: 24V DC
Output Current: 15 Amps
Output Rated Power: 360 Watts
Output Peak Power:
