1 to 10 4Pin Cooling Fans Hub Splitter Cable 12V PWM LED Sata Power Suppply Adapter Speed Controller For Computer

Features:

1: Expand the 4-pin connector of the 10-bit fan to solve the lack of motherboard connectors and concentrate on processing fan wires.

2: The pwm interface is connected to the motherboard cpu_fan interface, and the red is the dedicated interface for the cpu fan (with speed measurement function). The black interface is a pwm conventional fan interface (no speed measurement signal, but does not affect the pwm function). Note: To avoid speed measurement confusion, computer crashes, a multi-channel interface expanded from an interface, only display the speed measurement of one of the fans!

3: The power supply can be directly powered by the power supply, which can reduce the load pressure of the motherboard. The temperature control line PWM is connected separately from the motherboard, and the power supply and temperature control are both correct.

4: Application: suitable for 12V motherboard 3pin/4pin fan. 3pin fan can also be used, but it runs at full speed when plugged in, because 3pin fan has no PWM speed control function.

5. It supports PWM function automatic speed control fan. PWM interface is connected to the FAN CPU PWM motherboard cable interface. The interface is the dedicated orange interface for CPU fan, these black interface interface are conventional PWM fan.

Description:

SATA 1 to 10 way cooling fan hub splitter.Designed for 12 V 4-Pin fan, simultaneous support channel from 10 4-Pin fans, solve the problem of motherboard shortage.

EVA double-sided adhesive can be used to fix the hub in the chassis. Widely used for computer water cooling system.

Specifications:

Material: Plastic + Metal (Electric Components)

Main Color: Black

Package Included:

Notes:
