Partaker Micro Firewall Appliance, Firewall Mini PC, OPNsense, VPN, Industrial Mini PC, Ultra 5 125U, H11, 8 x 2.5G Lan, DP, HD, Type-C, RJ45 COM, DC 12V, 8G RAM, 128G SSD - OEM
Limited time offer, ends 12/25 By Partaker Mini PC‘s Marketplace
- This mini firewall PC boasts 8 x 2.5G LAN ports (1x i226-LM vPro-enabled, 7x i226-V), ensuring ultra-fast, secure, and stable network connections for your business or home needs.
- Harness the cutting-edge performance of the 14th Gen Core Ultra processor, delivering unmatched speed and efficiency for handling complex firewall tasks and multitasking with ease.
- Elevate your workspace with triple display support via 1 x HD, 1 x DP, and 1 x Type-C port. Streamline workflows and boost productivity by connecting multiple monitors effortlessly.
- Customize your setup with M.2 (NVME) SSDs, 2.5-inch HDDs/SSDs, WIFI, and 4G options. This mini PC adapts to your storage and networking preferences, offering flexibility and scalability.
- Choose between a fanless design for whisper-quiet operation in noise-sensitive environments or a fan-equipped version for superior cooling during intense workloads. Enjoy reliable performance tailored to your usage scenario.
+
+
Overview
Specs
Reviews
Model Number: Partaker H11
Chassis: Aviation grade aluminum alloy
Color: Metal gray (color can be customized freely)
CPU: Onboard Intel Core Ultra 5 125U (12 core 14 threads, Max Turbo 4.3 GHz, 15W )
NPU: Intel AI Boost (Max Frequency 1.4GH z)
BIOS: AMI EFI BIOS
Display Chip: Intel Graphics
Memory: 2 x DDR5 5600 SODIMM memory slot, Max 64 GB
Storage: Support 1 x M. 2 2280 slot, 1 x 2.5 -inch HDD/SSD
Display Port: 1 x HDMI, 1 x DP, 1 x Type-C, Resolution up to 4096x2160 @ 60Hz
Network Card: 7*Intel i226-V 100/1000/2500M Ethernet, 1*Intel i226-LM 100/1000/2500M Ethernet, support Intel vPro (LAN1)
Front I/O: 1 x Power Button, 1 Reset, 1 x Type-C (support DP/USB 3.2 /PD 5V1A), 1 x HD, 1 x DP, 4 x USB 3.2, 1 x RJ45 COM (suppor Console), 1 x SIM Card Slot
Rear I/O: 1 x DC, 8 x Intel 2.5G Lan (1 x Intel i226-LM support vPro, 7 x Intel i226-V)
Expansion: Support 1 x M. 2 2280 M-Key slot (NVME protocol, PCIE 4.0 x4)
Support 1 x M. 2 2230 E-key slot (PCIe&USB /CNVio2 )
Support 1 x M. 2 3052 (2242) B-key slot (USB 3.0 signal, supports 4G/5G), external SIM card slot
Expandable interface (not included in standard shipment) 2 USB 2.0, 4*Pin GPIO
Power: DC 12V Input
Work Temperature: 0°C ~ +40°C Commercial HDD, -20°C ~ +50°C Industrial SSD, surface air flow
Work Humidity: 5%~95% non-condensing
Other Function: Power On, Timed Power On, Network Wake-Up, PXE, Watchdog (0-255 Levels), TPM 2.0 Secure Encryption
Size: 170 x 140 x 58mm
Weight: 1.36 kgs
Application: Firewall, VPN, Network Server, Network Security, Router, and etc.
Packing List: Partaker H11 firewall appliance, power supply, power cord, vesa mount, warranty card
System Compatibility: 5.10. x and above core-based freebsd router systems, linux distros, or win. os supported.
Compatibility: firewalls for pfsense, opnsense and other popular open-source software solutions.
4-12 LAN/WAN Ports, Different CPU, Nano Type, Mini Type, 1U/2U rackable, 9-15 inch rackable, all are available in our shop,
Bookmark our store, for customization needs and other needs, we shall be glad to supply, contact us to get a timely reply
Chassis: Aviation grade aluminum alloy
Color: Metal gray (color can be customized freely)
CPU: Onboard Intel Core Ultra 5 125U (12 core 14 threads, Max Turbo 4.3 GHz, 15W )
NPU: Intel AI Boost (Max Frequency 1.4GH z)
BIOS: AMI EFI BIOS
Display Chip: Intel Graphics
Memory: 2 x DDR5 5600 SODIMM memory slot, Max 64 GB
Storage: Support 1 x M. 2 2280 slot, 1 x 2.5 -inch HDD/SSD
Display Port: 1 x HDMI, 1 x DP, 1 x Type-C, Resolution up to 4096x2160 @ 60Hz
Network Card: 7*Intel i226-V 100/1000/2500M Ethernet, 1*Intel i226-LM 100/1000/2500M Ethernet, support Intel vPro (LAN1)
Front I/O: 1 x Power Button, 1 Reset, 1 x Type-C (support DP/USB 3.2 /PD 5V1A), 1 x HD, 1 x DP, 4 x USB 3.2, 1 x RJ45 COM (suppor Console), 1 x SIM Card Slot
Rear I/O: 1 x DC, 8 x Intel 2.5G Lan (1 x Intel i226-LM support vPro, 7 x Intel i226-V)
Expansion: Support 1 x M. 2 2280 M-Key slot (NVME protocol, PCIE 4.0 x4)
Support 1 x M. 2 2230 E-key slot (PCIe&USB /CNVio2 )
Support 1 x M. 2 3052 (2242) B-key slot (USB 3.0 signal, supports 4G/5G), external SIM card slot
Expandable interface (not included in standard shipment) 2 USB 2.0, 4*Pin GPIO
Power: DC 12V Input
Work Temperature: 0°C ~ +40°C Commercial HDD, -20°C ~ +50°C Industrial SSD, surface air flow
Work Humidity: 5%~95% non-condensing
Other Function: Power On, Timed Power On, Network Wake-Up, PXE, Watchdog (0-255 Levels), TPM 2.0 Secure Encryption
Size: 170 x 140 x 58mm
Weight: 1.36 kgs
Application: Firewall, VPN, Network Server, Network Security, Router, and etc.
Packing List: Partaker H11 firewall appliance, power supply, power cord, vesa mount, warranty card
System Compatibility: 5.10. x and above core-based freebsd router systems, linux distros, or win. os supported.
Compatibility: firewalls for pfsense, opnsense and other popular open-source software solutions.
4-12 LAN/WAN Ports, Different CPU, Nano Type, Mini Type, 1U/2U rackable, 9-15 inch rackable, all are available in our shop,
Bookmark our store, for customization needs and other needs, we shall be glad to supply, contact us to get a timely reply
