Open_Box - Samsung 75" 4K UHD QB75C QBC Series LED-backlit LCD Display for Digital Signage (LH75QBCEBGCXGO)

Feature & Design:

Introducing QBC, an ultraslim Samsung UHD Signage display. It brings elegance to business while maximizing space. Its enhanced internal solutions and intuitive home screen UX make it easy to use. Businesses in various verticals can achieve growth with QBC's efficiency and design innovation.

Specifications:

Display

Diagonal Size: 75"

Panel Type: VA

Resolution: 3,840 x 2,160

Pixel Pitch (HxV): 0.429x0.429 mm

Brightness (Typ): 350 nit

Contrast Ratio: 4,000:1

Viewing Angle (H/V): 178/178

Response Time (ms): 8ms

Colour Gamut: 72% (NTSC)

Glass Haze: 2%

H-Scanning Frequency: 30~81kHz

Maximum Pixel Frequency: 594MHz

V-Scanning Frequency: 48~75Hz

Contrast Ratio (Dynamic): Mega

Operation Time Support: 16/7

Connectivity

HDMI In: 3

DP In: No

Version of HDMI: 2

Version of DP: No

Version of HDCP: 2.2

USB: 2

IR In: Yes

Audio In: No

Audio Out: Stereo Mini Jack

RS232 In: Yes

RS232 Out: Yes

RJ45 In: Yes

WiFi: Yes

Bluetooth: Yes

Power

Power Supply: AC100-240V 50/60Hz

Power Consumption (On Mode): 214.5 W

Power Consumption (Sleep Mode): 0.5 W

Dimension

Set Dimension (WxHxD): 1682.3 x 960.4 x 28.5 mm

Package Dimension (WxHxD): 1839 x 1113 x 180 mm

Weight

Set Weight: 33.4 kg

Package Weight: 43.5 kg

Operation Conditions

Temperature: 0~ 40

Humidity: 10 ~ 80%, non-condensing

Mechanical Specification

VESA Mount: 400 x 400 mm

Bezel Width: 13.4mm (even)

Bezel Colour: Charcoal Black

Frame Material: Non-Glossy

Optional Feature

Mount: WMN-B50SC

Stand: STN-L6585C

SoC

OS Version: Tizen 7.0

Flash Memory Size: 8GB

Certification and Compliance

EMC: Class B

Safety: 60950-1, 62368-1
