| Standards | IEEE 802.3af Power over Ethernet (PoE) IEEE 802.11a/b/g |
|---|
| Device Management | Remote configuration and management through Web browser, SNMP SNMP management supports SNMP MIB I, MIB II, and 802.11 MIB |
|---|
| Wireless Data Rates | Up to 108Mbps |
|---|
| Security | 40/64-, 128-, and 152-bit WEP encryption Block SSID Broadcast VPN pass-through support MAC address filtering with access control lists – up to 256 users 802.1x RADIUS support with EAP TLS, TTLS, PEAP Wi-Fi Protected Access (WPA2) Secure Socket Layer (SSL) remote management login |
|---|
| Frequency Band | 2.4 GHz / 5 GHz |
|---|
| Antenna | Dipole Antenna |
|---|
| Transmitted Power | 802.11b mode, 1 to 11 Mbps + 19 dBm 802.11g mode, 6 to 24 Mbps + 18 dBm 802.1g mode, 36, 48 and 54 Mbps + 17/16/16 dBm |
|---|
| Receiver Sensitivity | 802.11b 2 Mbps -94 dBm 5.5 Mbps -92 dBm 11 Mbps -90 dBm 802.11g 6 Mbps - 91 dBm 9 Mbps - 91 dBm 12 Mbps - 90 dBm 18 Mbps - 87 dBm 24 Mbps - 85 dBm 36 Mbps - 80 dBm 48 Mbps - 75 dBm 54 Mbps - 70 dBm 802.11a 6 Mbps - 92 dBm 9 Mbps - 91 dBm 12 Mbps - 90 dBm 18 Mbps - 86 dBm 24 Mbps - 84 dBm 36 Mbps - 79 dBm 48 Mbps - 72 dBm 54 Mbps - 70 dBm |
|---|
| Modulation | DSSS |
|---|
| System Requirements | Windows 98, Me, 2000 or XP 2 MB of available disk space |
|---|
| Interface | Ethernet Port |
|---|
| LEDs | Six LEDs: Power, Test, 100 Mbps, Link/ACT, and WLAN 802.11g |
|---|
| WAN Ports | 1 x 10/100M |
|---|
| Power Supply | 12 V DC, 1.0A 4.3 W |
|---|
