MSI Codex ZS 3-002BUS AMD B550 1 x HDMI Barebone
- AMD B550
- 4 x 288Pin DIMM DDR4 3200
Specs
Reviews (13)
Learn more about the MSI Codex ZS 3-002BUS
| Brand | MSI |
|---|---|
| Model | Codex ZS 3-002BUS |
| Cases | Forge 100R |
|---|
| North Bridge | AMD B550 |
|---|
| Memory installed | No Memory |
|---|---|
| Memory slot | 4 x 288Pin DIMM |
| Memory Type Supported | DDR4 3200 |
| Max Memory Supported | 128GB |
| PCI Express 4.0 x16 | 1 |
|---|---|
| PCI | 2 x PCIe 3.0 x1 |
| Hard Drive Installed | No Hard Drive |
|---|---|
| Serial ATA | 4 x SATA 6.0Gb/s |
| M.2 | 2 x M.2 (1 x PCIe 4.0 x4/SATA, 1 x PCIe 3.0 x4) |
| Onboard Audio | Realtek ALC1200 |
|---|---|
| Channel | 7.1-CH |
| First LAN | Realtek 8111HN |
|---|---|
| Wireless LAN | WiFi 6 (802.11ax) 2.4Gbps Dual Band 2.4GHz, 5GHz |
| Bluetooth | Bluetooth 5.1 |
| Max LAN Speed | 10/100/1000Mbps |
| 2.5" Internal bays | 3 x 2.5" |
|---|---|
| 3.5" Internal bays | 2 x 3.5" or 2.5" |
| Front USB | 2 x USB 3.2 Gen1 Type-A |
|---|
| VGA | 1 x D-Sub |
|---|---|
| DVI | 1 x DVI-D |
| HDMI | 1 x HDMI |
| Rear USB | 4 x USB 3.2 Gen1 Type-A 2 x USB 2.0 |
| Power Supply | 550W 80+ Bronze |
|---|
| Dimensions | 17.09" x 8.50" x 19.65" |
|---|---|
| Weight | 26.45 lbs. |
| First Listed on Newegg | May 19, 2021 |
|---|
