In-Win IW-IP-S300FF1-0 H In-Win Power Supply IP-S300FF1-0 H 300W TFX for BL-BP series Brown BOX
- TFX 12V V2.31
- 115 / 230 V
- +3.3V@16A, +5V@16A, +12V1@18A, +12V2@18A, [email protected], 5VSB@2A
+
+
Overview
Specs
Reviews (4)
Specifications
- Mfr Part Number: IP-S300FF1-0 H
- Features:
- Multiple +12V Output
- Smart Thermal Control to Balance Noise & Cooling
- MTBF 100KHRs @ 25 C per MIL-STD-217D/F
- Operating Ambient +10 C Minimum to +40 C Maximum
- Meets Intel Haswell Processors
- Maximum Power: 300 W (Support Haswell)
- Input: 115/230V AC
- Type: TFX12V v 2.31
- Fan: 1x 80mm Cooling Fan
- Output: + 3.3V @ 16A, +5V @ 16A, +12V1 @ 18A, +12V2 @ 18A, -12V @ 0.3A, +5Vsb @ 2.5A
- Connector: 1x 20+4Pin Main Power Connector, 1x 4+4Pin 12V CPU Connector, 3x SATA Connectors, 1x Peripheral Connector, 1x 4Pin FDD Connector
- Dimensions (WxLxH): 85.0 x 175.0 x 65.0 mm
