Features & Design:
Boost your workflow with the power of AI by keeping the 14" Dell Pro Max 14 Laptop with you on your travels. In addition to its thin and lightweight design, inside is an Intel Core Ultra 5 225H 14-Core Series 2 processor with a dedicated NPU that accelerates AI workloads. It is accompanied by 16GB of DDR5 LPCAMM memory and a 256GB SSD that helps you to quickly load and multitask applications.
Powered by integrated Intel Arc Graphics, the 1920 x 1200 resolution screen delivers rich visuals. Dual Thunderbolt 4 ports allow you to daisy chain up to 40 Gb/s devices and compatible monitors while the two USB-A ports work with up to 5 Gb/s peripherals. Wi-Fi 7 ( 802.11 be) support and a 10 Gb/s Ethernet port provide fast and reliable connections to compatible networks. Windows 11 Pro is preinstalled.
Intel Ultra Performance with Intel AI Boost
The Intel Core Ultra 5 225H powers applications with six Performance cores while the eight Efficiency and two Low-Power Efficiency cores handle background tasks. This processor has a 5.1 GHz Max Turbo frequency.
Supporting up to 13 TOPS, the integrated NPU accelerates the AI tasks for smoother performance when creating content and meeting online.
14" Full HD+ Display
Housed inside narrow bezels, the 14" display features a Full HD+ 1920 x 1200 resolution that allows you to see more than tradition Full HD screens.
The screen has 300 nits of brightness and covers 45% of the NTSC color space.
Visuals are handled by integrated Intel Arc Graphics.
Specification:
Key Specs
Operating System: Windows 11 Pro
Processor: Intel Core Ultra 5 225H
GPU: Intel Arc 130T
Installed RAM: 16 GB
Display Size: 14"
Native Resolution: 1920 x 1200
Touchscreen: No
Total Installed Storage: 256 GB
Inputs/Outputs: 2x USB-C (Thunderbolt 4), 2x USB-A 3.0 / 3.1 / 3.2 Gen 1
Display I/O: 1x HDMI 2.1 Output
Wi-Fi: Wi-Fi 7 ( 802.11 be)
Bluetooth: Bluetooth 5.4
Weight: 4.03 lb / 1.83 kg
Operating System: Windows 11 Pro
Performance
Processor: Intel Core Ultra 5 225H
CPU:
14-Core:, 1.7 to 4.9 GHz Performance (4 Cores), 1.3 to 4.3 GHz Efficiency (8 Cores), 0.7 to 2.5 GHz Low Power Efficiency (2 Cores)
Dedicated AI Cores: Yes: 13 TOPS
L3 Cache: 18 MB
GPU: Intel Arc 130T
Installed RAM: 16 GB
RAM Type: 7500 MT/s DDR5
RAM Configuration / Capacity: 1x User-Replaceable 16 GB Module / 1 Slots Supporting up to 64 GB (LPCAMM)
vPro Support: No
Display
Panel Type: VA LCD
Size: 14"
Aspect Ratio: 16:10
Native Resolution: 1920 x 1200
Touchscreen: No
Finish: Anti-Glare
Maximum Brightness: 300 nits / cd/m2
Color Gamut: 45% NTSC
Refresh Rate: 60 Hz
Contrast Ratio: 800:1
Response Time: 35 ms
Variable Refresh Technology: No
Viewing Angle (H x V): 170 x 170°
Storage and Expansion
Total Installed Storage: 256 GB
Storage Drive Type: 1x 256 GB / M. 2 NVMe SSD
Storage Expansion: Fixed Storage / Cannot Be Upgraded
Inputs / Outputs
Inputs/Outputs: 2x USB-C (Thunderbolt 4) / Supports Power Delivery, 2x USB-A 3.0 / 3.1 / 3.2 Gen 1
Display I/O: 1x HDMI 2.1 Output
Audio I/O: 1x 1/8" / 3.5 mm Headphone/Microphone Input/Output
Network I/O: 1x RJ45 (10 GbE)
Built-In Speakers: Yes: 2
Built-In Microphones: Yes: 2
Media/Memory Card Slot: No
Communications
Wi-Fi: Wi-Fi 7 ( 802.11 be); Tri-Band ( 2.4, 5, & 6 GHz) with MU-MIMO Support
Bluetooth: Bluetooth 5.4
Cellular Support: No
GPS: No
Webcam: Yes: User-Facing 1080p
Battery
Battery Chemistry: Lithium-Ion Polymer (LiPo)
Capacity: 4-Cell: 72 Wh
Keyboard & Mouse
Keyboard: Built-In Chiclet-Style Keyboard with Backlight
Pointing Device: TouchPad
General
Security: Dedicated Hardware TPM Security Chip, Webcam Blocker, Wedge-Shaped Lock Slot
Power Supply: 100 W with USB-C
Input Power: 100 to 240 VAC, 50 / 60 Hz
Dimensions: 12.3 x 8.9 x 0.97" / 313 x 227.3 x 24.65 mm
Weight: 4.03 lb / 1.83 kg
