SUPERMICRO CSE-216BAC-R920LPB Black 2U Rackmount Chassis 920W

Be the first to review this product...
  • 920W
  • 24x 2.5" SAS / SATA Hot-swap drive trays SAS or enterprise SATA HDD only recommended Hot-Swap Drive Bays
  • 3x 80mm 7000 RPM PWM fans 80mm Fans
Specs
Reviews

Learn more about the Supermicro CSE-216BAC-R920LPB

Model
Brand SUPERMICRO
Model CSE-216BAC-R920LPB
Details
Chassis Type Rackmount
Form Factor 2U
Color Black
Motherboard Compatibility E-ATX and ATX
Power Supply 920W
Expansion
Hot-Swap Drive Bays 24x 2.5" SAS / SATA Hot-swap drive trays
SAS or enterprise SATA HDD only recommended
Expansion Slots 7x low-profile expansion slots
Cooling System
80mm Fans 3x 80mm 7000 RPM PWM fans
Features
Features Backplane
SAS3 12Gb/s Direct Attached Storage Backplane

Front Panel
Buttons:
Power On/Off button
System Reset button
LEDs:
Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED
Power fail LED
Dimensions & Weight
Dimensions 17.2" x 3.5" x 24.8" (W x H x D)
Additional Information
First Listed on Newegg April 25, 2018

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 3 years
