ASUS TUF Z270 Mark 1 LGA1151 DDR4 DP HDMI M.2 USB 3.1 Z270 ATX Motherboard

ASUS TUF Z270 Mark 1 LGA1151 DDR4 DP HDMI M.2 USB 3.1 Z270 ATX Motherboard

Name: ASUS TUF Z270 Mark 1 LGA1151 DDR4 DP HDMI M.2 USB 3.1 Z270 ATX Motherboard
Brand: ASUS
SKU: N82E16813132934
Rating: 4 (35 reviews)

(35) Write a Review

OUT OF STOCK.

Fees for brokerage and duty included in price.

Intel Z270
Intel Socket 1151 for 7th/6th Generation Core i7/i5/i3/ Pentium/Celeron Processors
DDR4 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2666(OC)/ 2400(OC)/ 2133
* The maximum memory frequency supported varies by processor.

Overview

Specs

Reviews

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 5 years
Limited Warranty period (labor): 5 years
Read full details

Return Policies

Return for refund within: 30 days

Return for replacement within: 30 days

This item is covered by Newegg.ca's Standard Return Policy. Read full return policy for details.

CPU Socket Type	LGA 1151
CPU Type	Intel Socket 1151 for 7th/6th Generation Core i7/i5/i3/ Pentium/Celeron Processors
Supported CPU Technologies	Turbo Boost Technology 2.0 * Not Compatible with Intel 8th Gen CPUs

Number of Memory Slots	4x288pin (DDR4)
Memory Standard	DDR4 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2666(OC)/ 2400(OC)/ 2133 * The maximum memory frequency supported varies by processor.
Maximum Memory Supported	64GB
Channel Supported	Dual Channel

PCI Express 3.0 x16	2 x PCIe 3.0/2.0 x16 (x16 or dual x8) 1 x PCIe 3.0/2.0 x16 (max at x4 mode)
PCI Express x1	3 x PCI Express 3.0/2.0 x1 slots

SATA 6Gb/s	6 x SATA 6Gb/s port(s), gray
M.2	1 x M.2 Socket 3, with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)1 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)2 1. The M.2_1 socket shares SATA_1 port when use M.2 SATA mode device. Adjust BIOS settings to use a SATA device 2. vertical
SATA RAID	0/1/5/10

Audio Chipset	Realtek ALC S1220A
Audio Channels	8 Channels

SHOP WITH CONFIDENCE

Are you an E-Blast Insider?

ASUS TUF Z270 Mark 1 LGA1151 DDR4 DP HDMI M.2 USB 3.1 Z270 ATX Motherboard

Learn more about the ASUS TUF Z270 MARK 1

Customer Reviews of the ASUS TUF Z270 MARK 1

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

LAN Chipset	Intel I219-V
Second LAN Chipset	Intel I211
Max LAN Speed	2 x 1Gbps

HDMI	1 x HDMI
RJ45	2 x RJ45
DisplayPort	1 x DisplayPort
USB 3.1	1 x USB 3.1 Type-A 1 x USB 3.1 USB Type-C 2 x USB 3.1 Gen 1
USB 1.1/2.0	4 x USB 2.0 (one port can be switched to USB BIOS Flashback) 1 x TUF Detective USB port
S/PDIF Out	1 x Optical
Audio Ports	5 Ports

Onboard USB	2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) (19-pin) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
Other Connectors	1 x AAFP connector 1 x COM port(s) connector(s) 1 x CPU Fan connector(s) (1 x 4-pin) 1 x CPU OPT Fan connector(s) (1 x 4-pin) 5 x Chassis Fan connector(s) (5 x 4-pin) 1 x Assistant Fan connector(s) (1 x 4-pin) 1 x S/PDIF out header(s) 1 x Thunderbolt header(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) (Q-Connector) (Chassis intrusion header is inbuilt) 1 x 5-pin EXT_FAN (Extension Fan) connector 1 x MemOK! button(s) 1 x CPU OV 1 x Power-on button(s) 1 x Clear CMOS jumper(s) 1 x 14-1-pin TPM connector 1 x High AMP Fan header (4-pin) 3 x T_Sensor Connector

Form Factor	ATX
Dimensions (W x L)	12.0" x 9.6"
Power Pin	1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s)
