COMPACT WITH AN IMPACT - Measuring only 4.53" wide and 11.3" tall, the G22 gaming desktop can fit in even the most compact spaces despite of packing powerful hardware.
POWERFUL PERFORMANCE - The G22 takes Windows 11 gaming to the next level with an Intel Core i7-14700F Processor and NVIDIA GeForce RTX 4060 DUAL while only measuring 10L in volume.
MODERN DESIGN - Featuring a sleek and minimalistic design, the G22 can blend-in in any scenario, while subtle RGB lighting allows for additional personalization.
EASY ACCESS DESIGN - Get access to the internals of the G22 with just a slide, allowing you to upgrade components swiftly and effortlessly.
SPLENDID SOUND - Revel in the richness of Dolby Atmos audio support, recreating soundscapes exactly as the artists intended and keeping your communications clear with Two-Way AI Noise-Cancellation technology.
Overview
Specs
Reviews (39)
Learn more about the ASUS G22CH-DS764
Model
Brand
ASUS
Series
ROG
Model
G22CH-DS764
Part Number
90PF03T1-M00UZ0
Quick Info
Type
Gaming & Entertainment
Form Factor
Small Form Factor (10L)
AI Features
AI Ready
Usage
Consumer
Color
Gray
Processor
Intel Core i7-14700F 2.10 GHz
Processor Main Features
64 bit 20-Core Processor
Cache Per Processor
33 MB L3 Cache
Memory
16 GB DDR5
Storage
1 TB M.2 NVMe PCIe 4.0 SSD
Graphics
NVIDIA GeForce RTX 4060 DUAL 8 GB GDDR6
Power Supply
600W power supply (80+ Gold, peak 600W)
Operating System
Windows 11 Home 64-bit
Motherboard
Chipset
Intel B760
CPU
CPU Type
Intel Core i7 14th Gen
CPU Name
Intel Core i7-14700F
Turbo Frequency
Up to 5.40 GHz
L3 Cache Per CPU
33 MB
CPU Main Features
64 bit 20-Core Processor
Graphics
GPU/VGA Type
GeForce RTX 4060
GPU Memory
8 GB GDDR6
Virtual Reality Ready
Yes
Memory
Memory Capacity
16GB DDR5
Memory Spec
8 GB x 2
Memory Slot (Total)
2
Memory Slot (Available)
0
Maximum Memory Supported
32 GB
Storage
SSD
1TB PCIe
HDD
No
Optical Drive
Optical Drive Type
No
Audio
Audio Features
High Definition 7.1 Channel Audio
Communications
LAN Chipset
Realtek RTL8125BG
LAN Speed
2.5Gbps
WLAN
Wi-Fi 6E (802.11ax) (Dual band) 2*2
WiFi Generation
Wi-Fi 6E
Bluetooth
Bluetooth 5.3
Front Panel Ports
Front USB
1 x USB 3.2 Gen 2 Type-C 2 x USB 3.2 Gen 2 Type-A
Front Audio Ports
1 x 3.5mm combo audio jack
Back Panel Ports
Video Ports
1 x HDMI / 3 x DisplayPort
Rear USB
2 x USB 2.0 Type-A 2 x USB 3.2 Gen 1 Type-A
RJ45
1 port
Rear Audio Ports
3 ports
Expansion
PCI Slots (Available/Total)
1x PCIe 4.0 x 16 1x M.2 connector for WiFi
Mouse
Mouse Type
Wired optical mouse (USB)
Keyboard
Keyboard Type
Wired keyboard (USB)
Dimensions & Weight
Dimensions (H x W x D)
11.30" x 4.53" x 12.72"
Weight
18.52 lbs.
Additional Information
First Listed on Newegg
October 03, 2024
