Item#: N82E16817139005

CORSAIR TX Series CMPSU-650TX 650W ATX12V / EPS12V SLI Ready CrossFire Ready 80 PLUS BRONZE Certified Active PFC Compatible with Core i7 Power Supply & New 4th Gen CPU Certified Haswell Ready

  • ATX12V / EPS12V
  • 80 PLUS BRONZE Certified
  • 100 - 240 V 47 - 63 Hz
  • +3.3V@30A, +5V@30A, +12V@54A, -12V@0.8A, +5VSB@3.0A
  • Pin It
  • Email this page
ICON Loading...

Learn more about the Corsair CMPSU-650TX

Model

Brand
CORSAIR
Model
CMPSU-650TX
Series
TX Series

Spec

Type
ATX12V / EPS12V
Maximum Power
650W
Fans
1
PFC
Active
Main Connector
20+4Pin
+12V Rails
Single
PCI-Express Connector
2 x 6+2-Pin
SATA Power Connector
8
SLI
SLI Ready
Haswell Support
Yes
CrossFire
CrossFire Ready
Modular
No
Efficiency
> 80%
Energy-Efficient
80 PLUS BRONZE Certified
Over Voltage Protection
Yes
Input Voltage
100 - 240 V
Input Frequency Range
47 - 63 Hz
Input Current
4 - 12A
Output
+3.3V@30A, +5V@30A, +12V@54A, -12V@0.8A, +5VSB@3.0A
MTBF
100,000 Hours
Dimensions
5.9"(W) x 3.4"(H) X 6.3"(L)
Weight
7.2 lbs.

Features

Connectors
1 x Main connector (20+4Pin)
1 x 4+4 Pin CPU
8 x Peripheral
8 x SATA
3 x Floppy
2 x PCI-E
Features
Fanless mode at low loads for quiet operation, with an ultra-quiet 140mm double ball-bearing fan that delivers excellent airflow when needed.

50C temp rating and industrial-grade 105C primary capacitors ensure the five year warranty for peace of mind.

Up to 85% energy efficiency means less heat generation and lower energy bills.

0.99 Active Power Factor Correction provides clean and reliable power.

Universal AC input from 100~240V.

A dedicated single +12V rail offers maximum compatibility with the latest components.

Over-voltage and over-power protection, under-voltage protection, and short circuit protection provide maximum safety to your critical system components.

Extra long fully-sleeved cables support full tower chassis.

It supports the latest ATX12V v2.3 standard and is backward compatible with ATX12V 2.2 and ATX12V 2.01 systems.

Manufacturer Warranty

Parts
5 years limited
Labor
5 years limited

Quick Info


Customer Reviews of the Corsair CMPSU-650TX

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • N/A
  • 4/13/2014 1:08:00 PM
  • Tech Level: High
  • Ownership: more than 1 year
  • Verified Owner

5 out of 5 eggsRock Solid

Pros: I've had this PS for going on 4 years. With the exception of the occasional power loss to the house, this PS hasn't been turned all this time.

Cons: I don't know about the noise issues since I keep my system in the basement. In any case, if there is a noise it hasn't affected the performance at all.

Did you find this review helpful? Yes No

  • N/A
  • 3/25/2014 2:37:01 PM
  • Tech Level: Somewhat High
  • Ownership: more than 1 year
  • Verified Owner

5 out of 5 eggs4 years and going strong!

Pros: Bought back in January of 2010 (price hasn't changed at all) for my first gaming PC build. I've never had a single issue with it and have been running my PC steadily since then.

Cons: None.

Other Thoughts: I don't do much on overclocking or stress testing on the PC and this is a bit overpowered for my build, so I imagine that helps longevity.

Did you find this review helpful? Yes No

  • QuadroNVS
  • 3/23/2014 11:45:30 PM
  • Tech Level: Average
  • Ownership: more than 1 year
  • Verified Owner

5 out of 5 eggsThe bold and the Powerful

Pros: I have had this PSU for over one year and it is a tank, it has run anything veI thrown at it and ran it with no issues....i have dual 6870s with an Phenom X6 overclocked and no issues so far.

Cons: Its not modular.....it was a pain to install this in my mid tower case

Other Thoughts: well newegg is out of stock but since this is corsair's V1 I would recommended their newer version which has less issues with the "smart fan"

Did you find this review helpful? Yes No

  • Ashe0211
  • 3/19/2014 3:45:29 PM
  • Tech Level: Average
  • Ownership: more than 1 year

3 out of 5 eggsGood but....

Pros: Worked great, it powered two 8800GTX's no problem. Then I upgraded to a 500 Series card. Worked great until....

Cons: It burned out after 2 years of use. Couldn't find the receipt and had to bite the bullet on this one.

Other Thoughts: I know things go bad sometimes but man that was a short period. I still have an old 600w Ultra that works, not well but it still powers my computer.

Did you find this review helpful? Yes No

  • N/A
  • 3/16/2014 12:47:33 AM
  • Tech Level: High
  • Ownership: more than 1 year
  • Verified Owner

5 out of 5 eggs

Pros: This PSU has been in a system that gets daily use for over 3 years now and is still going strong. I have purchased two of these and neither one of them have given me an issue.

Cons: None.

Other Thoughts: Although I have transferred it around several times to different setups for the most part this one has been in a i7 920, P6x58D prem. MSI 460 talon, 500 gb. without issue.

Did you find this review helpful? Yes No

  • N/A
  • 3/11/2014 2:34:29 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsGreat Power Supply

Pros: Easy to install and get running.

Cons: None

Other Thoughts: Buy modular if you can spare the expense. Having extra wires is just a pita as well as an extra burden on cooling.

Did you find this review helpful? Yes No

  • Joe
  • 2/18/2014 5:49:51 PM
  • Tech Level: Somewhat High
  • Ownership: 1 day to 1 week
  • Verified Owner

2 out of 5 eggsNot Impressed

Pros: It provides power

Cons: The power supply fan started to hesitate to start randomly, did some research and found a bunch of other people had this issue as well. I went and bought ANOTHER Corsair at a local store and that one started make a loud pitched piercing noise when it was being stressed. I went with another brand and won't be returning to Corsair.

Did you find this review helpful? Yes No

  • N/A
  • 2/16/2014 5:23:31 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

4 out of 5 eggsGreat PSU

Pros: - Great color scheme
- Tons of power, especially on the 12v rail
- Long cables
- All the cable types and amounts that you could possibly want
- Third purchase of this PSU and it has not let me down yet

Cons: - Length and amount of cables can make for a potential cable management nightmare

Other Thoughts: - PSU did not come in a felt bag like all of my other Corsair PSU purchases. This makes me feel like it is refurbished or something fishy is going on. I purchased the PSU a little over a month ago and just now realized it when I went to look for the bag. I will be contacting Newegg with regards to this matter and will adjust egg rating accordingly.

Did you find this review helpful? Yes No

  • Matt_F
  • 1/29/2014 8:57:13 AM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year

1 out of 5 eggsFaulty Product, AMAZING SUPPORT

Pros: Great PSU, Great Company.

Cons: Faulty Fan Design. It sorta makes a jittery noise from stop/starting at certain power draw levels.

Other Thoughts: I would avoid this unit. Buy from this company.

Did you find this review helpful? Yes No

  • Clay
  • 1/22/2014 2:12:34 PM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month
  • Verified Owner

1 out of 5 eggsFan broken on arrival

Pros: Plenty of cables, looks high quality

Cons: Fan constantly starts then stops 2 or 3 times per second, causing it to wobble back and forth and make odd sounds. When fan does decide to run, has an audible tick to it. Will be returning.

Did you find this review helpful? Yes No
