Okay, it's a power supply. Not much excitement there unless it starts smoking, right? But this one is so cool, it's smokin'! Like the 52 Ampere +12V rail (and there's just the one +12V rail, so you don't have to balance your power needs by hand.). How about the ability to auto-sense your input voltage from 90Vac to 264Vac, 50/60Hz? No more voltage selector switches!
Run cooler, too, because it can be up to 80% efficient (tested at 20%, 50% and full load), meaning less waste heat from the supply. Compatible with both ATX 2.0 and ATX 2.2 systems, it includes long cables for even full-sized tower installations. Nvidia SLI support. It includes power connections for eight SATA drives. A 120mm variable speed fan with double bearings gives good airflow with minimal noise. Active power factor correction helps deal with inductive loads (drive and fan motors, mostly).
Give your computer a power supply that can keep up with the times.
-
- 5
-
- 81%
- 4
-
- 10%
- 3
-
- 2%
- 2
-
- 3%
- 1
-
- 4%
| Product Rating: |
|
| Total Reviews: |
889 |
perfect so far
- Pros: This PSU worked out of the box. Not one single problem, i suppose the first two guys with DOA's just got a bad lot. Anyhow, I LOVE the cabling, it installs very clean. More than enough hook-ups for 90% of people out there. 650w will run a pretty decent load even with a lot of SLI setups. Definitely recommend this PSU.
- Cons: none so far
- Other Thoughts: 100,000 MTBF means that if you left this running till it failed if would run for approx. 11 years. Look at the certifications and primarily the high potential amperages; this thing could power a welder if it needed to. Very robust.
- Pros: Stable voltage even under rather heavy load.
- Cons: The 2x 4 ATX12v wires were about 3" to short for my CM690 case.
- Other Thoughts: Corsair sure knows how to pack a box, it looked like you could drop the box from 10' and not hurt the psu inside.
| Model | CMPSU-650TX |
| Type | ATX12V / EPS12V |
| Maximum Power | 601 - 700W |
| Fans | 1 |
| PFC | Active |
-
- 5
-
- 81%
- 4
-
- 10%
- 3
-
- 2%
- 2
-
- 3%
- 1
-
- 4%
| Product Rating: |
|
| Total Reviews: |
889 |
Solid
- Pros: This is my third Corsair PS. Had to replace my Corsair 450VX as I just purchased Radeon 5850 and was afraid that my old ps would not handle it. This is a very reliable and very quiet power supply. Not sure if it is certified to run two 5850s in crossfire, but it certainly has no problems with one highly overclocked 5850. Five year warranty is a plus.
- Cons: None
- Other Thoughts: My two other corsair power supplies are still running (400 and 450VX). I bought this over a month ago and I hope it will run for the next five years. Another solid product from Corsair. Thanks!
Rock Solid Powerhouse
- Pros: I cannot say enough good things about Corsair PSU's in general, and this one is no exception. With 52A on a single 12V rail it can provide more power than many PSU's with much higher power ratings. Don't think this will be enough power? I have run...though wouldn't recommend for long term use... 2 x 5870's with an i7 920 overclocked to 4.3Ghz + 4 x 7200RPM HD's. It didn't blink while running benchmarks... but it got pretty hot. For 95% of people this power supply offers more than adequate power... The 5 year warranty is just a plus.
- Cons: The cables can be a bit difficult to manage in a small case, or in a case without cable management. Only has 2 x PCIe 6+2 pin connectors.
Finally!!!!!
- Pros: Quiet! Plenty of cables. It does feel like you're unpacking a weapon from a movie! a black cloth bag inside black styrofoam with black screws. They even include zip ties.
- Cons: None
- Other Thoughts: I originally wanted to save a few bucks and bought the OCZ Stealth Extreme 700w but everyone was reporting that it was going dead. I couldn't stand the worrying and returned it. I picked this one up.
Sure it's not modular but if you want modular you pay more $$. My last build was modular and for sure it was cool but I'm not in my case all the time like I used to be.
MSI 980a
Phenom 550 Black
4GB GSkil DDR3 1600
EVGA GTX260
HAF 922
| Model |
| Brand |
CORSAIR |
| Model |
CMPSU-650TX |
| Spec |
| Type |
ATX12V / EPS12V |
| Maximum Power |
650W |
| Fans |
Thermally controlled 120mm fan |
| PFC |
Active |
| Main Connector |
20+4Pin |
| +12V Rails |
Single |
| PCI-Express Connector |
2 x 6+2-Pin |
| SATA Power Connector |
8 |
| SLI |
Ready |
| CrossFire |
Ready |
| Modular |
No |
| Efficiency |
> 80% |
| Energy-Efficient |
80 PLUS Certified |
| Over Voltage Protection |
Yes |
| Input Voltage |
100 - 240 V |
| Input Frequency Range |
50/60 Hz |
| Input Current |
10A |
| Output |
+3.3V@24A,+5V@30A,+12V@52A,-12V@0.8A,+5VSB@3.0A |
| MTBF |
>100,000 Hours |
| Approvals |
UL, CE, CB, TUV, FCC, CCC |
| Dimensions |
5.9"(W) x 3.4"(H) X 5.9"(L) |
| Features |
| Connectors |
1 x Main connector (20+4Pin)
1 x 12V(4/8Pin)
8 x peripheral
8 x SATA
2 x Floppy
2 x PCI-E |
| Features |
Ultra-quiet 120mm double ball-bearing fan delivers excellent airflow
80%+ energy efficiency at 20%, 50% and 100% load condition for less heat generation and lower energy bill
99% Active Power Factor Correction provides clean and reliable power to your system
Universal AC input 90~264V automatically scans and detects the correct voltage
Dedicated single +12V rail offers maximum compatibility with latest components
Compatible with Core i7 |
| Manufacturer Warranty |
| Parts |
5 years limited |
| Labor |
5 years limited |
Introduction
Okay, it's a power supply. Not much excitement there unless it starts smoking, right? But this one is so cool, it's smokin'! Like the 52 Ampere +12V rail (and there's just the one +12V rail, so you don't have to balance your power needs by hand.). How about the ability to auto-sense your input voltage from 90Vac to 264Vac, 50/60Hz? No more voltage selector switches!
Run cooler, too, because it can be up to 80% efficient (tested at 20%, 50% and full load), meaning less waste heat from the supply. Compatible with both ATX 2.0 and ATX 2.2 systems, it includes long cables for even full-sized tower installations. Nvidia SLI support. It includes power connections for eight SATA drives. A 120mm variable speed fan with double bearings gives good airflow with minimal noise. Active power factor correction helps deal with inductive loads (drive and fan motors, mostly).
Give your computer a power supply that can keep up with the times.
Highlights
 |
ATX12V and EPS12V Compatible
Compatible with the ATX12V v2.2 and EPS12V standards, the Corsair CMPSU-650TX provides maximum power stability to drive the latest Intel and AMD processors as well as other components for desktop and server computer systems.
|
 |
650W Maximum Power
A maximum power of 650W delivers safe, reliable output for high-end PC systems.
|
 |
Highly Efficient
Delivering over 80% efficiency, the Corsair CMPSU-650TX power supply saves energy and may even reduce your electric bill!
|
 |
NVIDIA SLI Certified
Featuring two 6+2-pin PCI-E power connectors, the Corsair CMPSU-650TX power supply has gone through a series of rigorous NVIDIA SLI certification tests for maximum system stability when building NVIDIA SLI PCs.
|
Quick Specs
| Brand | CORSAIR |
| +12V Rails | Single |
| Efficiency | > 80% |
| Input Frequency Range | 50/60 Hz |
| Input Voltage | 100 - 240 V |
| Main Connector | 20+4Pin |
| Maximum Power | 601 - 700W |
| PCI-Express Connector | 2 x 6+2-Pin |
| PFC | Active |
| Type | ATX12V / EPS12V |
|
Reviewed By: on 11/29/2007
Tech Level: high - Ownership: 1 day to 1 week
