Item#: N82E16813130663

MSI FM2-A85XA-G65 FM2 AMD A85X (Hudson D4) HDMI SATA 6Gb/s USB 3.0 ATX AMD Motherboard

BIOS support New Richland/ Trinity APU


  • AMD A85X (Hudson D4)
  • APU (FM2 Socket)
  • DDR3 2400(OC)/2133(OC)
ICON Loading...


MSI FM2-A85XA-G65 FM2 AMD A85X (Hudson D4) - HDMI - SATA 6Gbps - USB 3.0 - ATX AMD Motherboard



World's First UEFI and Software Graphical User Interface

MSI ClickBIOS II provides a consistent user interface both in the UEFI BIOS and in Windows, it provides the most convenient way for users to control system settings and supports touchscreen control.


  • Graphical User Interface, with touchscreen support
  • Simply click or touch and move to change settings
  • Full system control, including overclocking, security and information




All Solid Capacitors

Capacitors are the most important component for electronic product's power supply. The quality of the capacitors can impact the stability of the entire system and risk of product failure. Currently there are two types of capacitors, electrolytic capacitors and solid capacitors. Compared to electrolytic capacitors, solid capacitors have a longer lifespan and provide a more stable power under high temperatures. More importantly, solid capacitors do not have any liquid materials inside, and thus will not suffer a leak which would infringe upon the product's stability. With such benefits is it no wonder that solid capacitors are very important for product quality's improvement.


AMD CrossFire

AMD CrossFireX™ is the ultimate multi-GPU performance gaming platform. Enabling game-dominatig power, AMD CrossFireX technology enables two or more discrete graphics processors to work together to improve graphics performance. AMD CrossFireX technology allows you to expand your system's graphics capabilities. It allows you the ability to scale your system's graphics horsepower as you need it, supporting up to four AMD Radeon™ HD graphics cards, making it the most scalable gaming platform ever. With an AMD CrossFireX gaming technology, the traditional graphics limitation exists no more, allowing you to enjoy higher performance as well as an improved visual experience.


DigitALL Power

Equipped with a digital PWM controller, DigitALL Power ensures an efficient, precise and stable power delivery to motherboards. With DigitALL power, MSI A85X motherboards provide an efficient and reliable platform for gaming, multimedia, and a wide variety of applications.


  • Higher power efficiency
  • Faster power transmission speed
  • Programmable microprocessor inside



Military III

MSI motherboards maintain their commitment to product stability and reliability by introducing Military Class III components including Hi-c CAP, SFC, and Solid CAP, which have passed MIL-STD-810G certification, making MSI's Military Class III components synonymous with premium quality and ultimate stability.


USB 3.0

Compared to the 480Mbps provided by traditional USB 2.0, the all-new USB 3.0's 5Gbps offer 10 times the transfer bandwidth, so transferring a Blu-ray movie takes less than one minute. MSI also has implemented a front panel USB 3.0 port, making the use of an external USB 3.0 device even more convenient.


  • 10X Faster than USB 2.0
  • Up to 5Gbps data transfer bandwidth
  • World's first to provide front panel USB 3.0 port
  • Boost transfer rates between your PC and external storage devices



HDMI v1.4 (AMD)

HDMI - High-Definition Multimedia Interface - is a new generation, fully digital video/audio interface which can transfer 1080p High-Definition video and audio output in a single, compact connector. Supporting HDCP copy protection such as Blu-ray Discs, HDMI provides you with the highest-quality home theater experience.


  • Next-gen multimedia interface
  • Delivers full HD video and audio output in only one cable




Mobile consumer appliances are getting more and more attention in our current-day, fast moving life style, with smart phones and tablets almost becoming a fashion accessory. However, many ordinary personal computers cannot charge some of these devices, making it difficult to stay connected. The MSI i-Charger is a Windows resident program capable of revising the power supply mode of your USB port to become more powerful. Once your phone or tablet is connected to your USB port, the i-Charger sends a signal to initiate its charging circuit, making it a really smart and convenient charging solution for mobile computing needs.


  • Automatically detects and charges your smartphone or tablet
  • Support Microsoft Windows 98SE / ME / 2000 / XP / Vista / 7, 32-Bit



AMD Dual Graphics

  • The GPU's computing power can be enhanced through the collaborative computing of video cards and APUs
  • Supports AMD Radeon HD 7670 / 7570 / 7470 graphics cards
  • MSI pushes the AMD Dual Graphics technology to their maximum potential



OC Genie II

OC Genie II provides an instant performance boost, optimizing CPU, memory, integrated graphics, and storage device performance when enabled.


  • Overclock in one second
  • At least 15% boost in 3D gaming performance
  • Simple and easy – No need for complex BIOS settings and extra equipment
  • *Features may vary according to your platform and model.



Winki 3

Winki 3 is a free Linux-based OS which is based on the Linux core. With an ultra-fast boot speed and a multi-language interface, the built-in Winki 3 provides an easy-to-use internet environment that includes the most popular functions, such as internet surfing, web mail, instant messaging, picture browsing, and more. It's the most practical way to get online in the shortest time.


  • User friendly and totally free applications
  • Power on to run applications in 25 seconds
  • Multi-language interface support




Compared to common motherboards which need extra BIOS chips, MSI's M-Flash has a double advantage which doesn't need extra components and secondly, all your BIOS data will be saved in the USB drive. The stored data does not only have backup and upgrade function, moreover it can also be seen as a portable BIOS chip which is actually able to boot up your PC.


  • Backup/restore your BIOS to/from any USB flash disk
  • Avoid unnecessary repair due to accidental failures during the upgrading process
  • Increase BIOS lifespan by reducing unnecessary rewrites



USB Safeguard

USB Safeguard can prevent motherboards and USB devices from being damaged by short-circuit and ESD - Electro-Static Discharge - with Anti-ESD chips built-into the motherboards. Additionally, the safeguard can protect against such dangers multiple times, and greatly improves product lifespan.


  • All MSI motherboards use USB Safeguard's anti-ESD chip for thorough protection against ESD damage
  • USB Safeguard is protected against a short circuit and/or ESD without the need for a fuse. It also supports stand-by power supply



Live Update 5

MSI Live Update 5 is a powerful and useful application for updating the latest BIOS and Drivers, saving you time and lowering the risk of updating. End-users can install and run the Live Update 5 software on their computers with the companion CD or downloading the app from the MSI website.


  • Automatically Detect the BIOS / Driver / VGA / Utility Update
  • Support Microsoft Windows 98SE / ME / 2000 / XP / Vista / 7, 32-Bit



SATA 6Gbps

SATA 6Gbps provides double the bandwidth of traditional SATA 3Gbps, and increases the data transfer rates between your motherboard and internal storage devices, such as 7200RPM HDDs and 10,000RPM HDDs and SSDs. It's also the current trend for upcoming high-speed internal storage devices to to break the existing bottleneck of a PC's performance.


  • 2X Faster than SATA 3Gbps
  • Up to 6Gbps data transfer bandwidth
  • Unleash the true performance of new HDDs/SSDs



Cool n' Quiet

AMD Cool n' Quiet™ Technology reduces heat and noise so you can experience amazing performance without distraction. Core enhancements included in the AMD processors can improve overall power savings, deliver better multitasking, and increase energy efficiency. Cool n' Quiet technology can automatically adjust the processor ratio to throttle CPU speeds with four modes.


  • Independent Dynamic Core Technology
  • Dual Dynamic Power Management™
  • AMD CoolCore™ Technology
  • AMD Wideband Frequency Control
  • Multi-Point Thermal Control



Learn more about the MSI FM2-A85XA-G65



Supported CPU

CPU Socket Type
CPU Type
APU (FM2 Socket)


AMD A85X (Hudson D4)


Number of Memory Slots
Memory Standard
DDR3 1066/1333/1600/1866/2133/2400*(OC)
Maximum Memory Supported
Channel Supported
Dual Channel

Expansion Slots

PCI Express 2.0 x16
2 (x16 or x8/x8)
PCI Express x1
PCI Slots

Storage Devices

SATA 6Gb/s
8 x SATA 6Gb/s

Onboard Video

Onboard Video Chipset
Supported only by CPU with integrated graphic

Onboard Audio

Audio Chipset
Realtek ALC892
Audio Channels
8 Channels

Onboard LAN

LAN Chipset
Realtek 8111E
Max LAN Speed

Rear Panel Ports

1 x PS/2 keyboard/mouse port
Video Ports
D-Sub + DVI
1 x HDMI
1 x DisplayPort
USB 1.1/2.0
4 x USB 2.0
USB 3.0
2 x USB 3.0
1 x Optical
Audio Ports
6 Ports

Internal I/O Connectors

Onboard USB
2 x USB 3.0 + 6 x USB 2.0
Other Connectors
1 x ATX 24-pin power connector
1 x ATX 8-pin 12V CPU power connector
CPU x 1 / System x 4 FAN connectors
1 x Front panel audio connector
1 x Front panel connector
1 x Clear CMOS jumper
1 x Chassis Intrusion connector
1x MultiConnect Panel connector
1x Power button
1x Reset button
1x OC Genie button
1x Clear CMOS button
1x Voltage Checkpoints connector

Physical Spec

Form Factor
12.0" x 9.6"
Power Pin
24 Pin


Military Class III components: Top quality & stability

OC Genie II: Auto OC to boost performance in 1 sec

ClickBIOS II: Easy-to-use UEFI BIOS interface

Super Charger: fast charge iPad/iPhone/smartphone

Support USB 3.0 & SATA 6Gb/s

Quick Info


  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years

Customer Reviews of the MSI FM2-A85XA-G65

Do you own this product? Write a Review

ICON Loading...

Filter Results

  • A loner
  • 1/21/2014 4:18:33 AM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsGreat FM2 Board

Pros: - Built with quality
- Very appealing design
- 4 memory slots
- USB 3.0
- O.C. Button and CMOS reset on the board

Cons: - Initial BIOS boot is a bit long, but not too long. (very minor con)

Other Thoughts: I've had this board for roughly 9 months now and it hasn't let me down at all. It has everything I personally look for in a motherboard. I apologize for not going more in-depth with this review, but all I can say is it is worth the buy for your FM2 setup. This board will bring me back to MSI for my future motherboard purchases.

Did you find this review helpful? Yes No

  • BJohnson
  • 12/30/2013 9:54:02 AM
  • Tech Level: High
  • Ownership: 1 week to 1 month

5 out of 5 eggsRock Solid Platform

Pros: Used this mobo in combination with an AMD A10-6800K processor and AMD Performance 1866mhz DDR3 RAM. Was amazed with the performance out of the box without using a discreet graphics card or AMD's Dual Graphics capabilities. Of course, I won't be doing any major gaming with this setup but still I was amazed by it's capabilities, even before enabling any overclocking. The sound quality from the onboard Realtek THX was impressive. The BIOS preloaded on this board when I received it was compatible with the new A10-6800k processor.

Cons: None really.

Other Thoughts: I have used MSI products for the last 10 or so PC's I have built and I have not ran into any problems. Their build quality is top notch! I guess I am either extremely lucky or just successful by using proper techniques and extreme care when building a machine. There are too many videos out there on the web that demonstrate bad build techniques such as mounting the RAM, CPU, and Cooling solution before even mounting the MB into the case or not demonstrating using proper grounding techniques. Not saying that there is a 0 chance of receiving a DOA item from any manufacturer but following correct building practices will help minimize your risk of encountering problems during your build.

Did you find this review helpful? Yes No

  • Mike
  • 12/28/2013 1:01:28 AM
  • Tech Level: Somewhat High
  • Ownership: 1 day to 1 week

5 out of 5 eggsMisinformed due to review here

Pros: It's a great quality motherboard and it quite a looker too. The bios are very friendly and easy to use and it was very easy to install everything. Was done in under 5 minutes.

Cons: If you're looking to upgrade to an APU there really are no cons. This is an amazing board.

Other Thoughts: Might say that the purchase isn't verified, but that's because I received it as a gift from my wife on her account. I wanted to upgrade my system as I haven't upgraded in years and I didn't do much research this time around and I made some big mistakes. Went from a Q9550 to an A8 6600K which wasn't really an improvement and I went with this board because one of the reviewers indicated that it supported SLI. It Does not support SLI!!! Do not make the mistake I did! No where does the product even indicate supporting SLI. I'm very disappointed, but not in the product just my lack of research into the parts I was getting.

Did you find this review helpful? Yes No

  • Nick
  • 12/10/2013 2:28:12 PM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsGood

Pros: Looks good good for apu A10 and A8 works well for over clocking

Cons: the price get it on sale and its good

Did you find this review helpful? Yes No

  • cabledog2tuff4u
  • 11/27/2013 8:31:55 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsBANG BANG

Pros: excellent work station
supports 3 monitors , no vid card needed
excellent workstation for small business, work production, can play most older games , cod1 , halo , cod2, doom, etc... , other new games such as bf4 and cod ghosts may require a GPU such as r290X

Cons: was not free

Other Thoughts: paired with
AMD APU A10 6800K @ 4.4 Ghz
4 X4 Gigs of gskill 2133 Mhz ddr3 ram
24x dvdr sata optic drive
500 Gig WD hdd

Did you find this review helpful? Yes No

  • jam1973
  • 11/23/2013 9:03:49 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsMSI Rocks

Pros: Easy Install Drivers for it install easy When you pick mobo up it is solid heavy millitary grade parts deff. I love it have built two systems with this now and so happy. pared with richland a-10 6800 great great easy overclock takes just about any memory so your selection is huge

Cons: none

Did you find this review helpful? Yes No

  • Killertomato
  • 11/19/2013 8:43:47 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsExcellent Motherboard

Pros: Used this board in a build last tax season, and I am extremely happy with the purchase. Everything about setting it up was easy EXCEPT for updating drivers for windows 8. But this was a windows 8 problem, not the board's fault.

Very simple overclocking (manually at least, i'm not a fan of one touch overclocking via oc genie or similar concepts) Got my A10-5800k up to 4.2ghz right out of the box, easy setup of my 2133mhz G.Skill ram, and dual graphics was as easy as a click of the mouse.

Cons: None that i've found yet.

Other Thoughts: I was originally running the a10-5800k apu with a 6670 discreet card for dual graphics, and it worked well enough. Since then I have gone the way of a more powerful single discreet card, but if you're on a budget this will definitely get you by for gaming, as long as you understand you can't max your settings.

Did you find this review helpful? Yes No

  • N/A
  • 10/27/2013 10:39:45 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggs

Pros: Great mobo for a great price, plenty of ports for a decent build. Well built, Quality.

Cons: None, had no issues with anything. Packaging and packing was all in order and the product has done nothing but worked as should.

Other Thoughts: MSI has earned a check in my go to book for my next motherboard purchase.

Did you find this review helpful? Yes No

  • HelpFile
  • 10/17/2013 11:40:58 AM
  • Tech Level: Average
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsUpdate to previous review.

Pros: SATA 6.0 GB/s, USB 3.0 & front panel header, ample fan headers, excellent onboard cooling, lots of USB & audio connectors. This board has everything most users will ever need.

Cons: Upgrade to Richmond CPU somewhat of a hassle. Downloaded Live Update 5 and used it to install new BIOS hoping to ensure compatibility. The program updated to the "latest" BIOS of 1.7.

When I installed the new Richmond CPU, the computer gave the message that the BIOS was incompatible. Turns out that 2.4 is the most current BIOS, and 2.x is required to run Richmond or do a BIOS flash. Had to switch back to Trinity, download 2.4, install to flash drive, and run it before the Richmond would work.

The upgrade was completed but at the expense of time in internet research and extra component swapping. And I like to keep handling of components to a minimum as it has its own inherent dangers such as wearing out contacts, ESD, bending pins etc...

Hopefully the board now comes with the latest BIOS, and if it doesn't, then hopefully this review simplifies the process for the reader. If it only has BIOS 1.x, you'll need a Trinity or Llano chip to accomplish the BIOS update, so you will either need to RMA the board and get something different or purchase a cheap CPU.

Other Thoughts: Despite this upgrade hassle, the system is running great and I couldn't be more satisfied with the hardware.

Richmond 3.8 Ghz Quad
2x8GB Crucial Ballistix 8-8-8-24
1TB Toshiba SATA 6.0 GB/s HD
Radeon HD 7790 2GB
Rosewill Capstone 450W Gold PSU

1 out of 1 people found this review helpful. Did you? Yes No

  • N/A
  • 10/16/2013 10:26:21 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsEasy

Pros: Easy OC, Easy BIOS, Price

Cons: None

Other Thoughts: Running my A10-5800K with this OC'd @ 4.3GHz, works great. Easy bios to navigate. MSI is the best.

Did you find this review helpful? Yes No
